Delta VFD110VL43C-J User Manual

APX A Optional Accessories | VFD-VJ
Apx A-10
A-4-1 AC Reactor
Specifications: AC Input Reactor
Air Cooled
200V~230V/ 50~60Hz model VFDXXXVL23C-J series AC Input Reactor
Model KW HP
Rated Current Saturation Current 3% Reactor 5% Reactor 3% Input Reactor:
(Arms) (Arms) (mH) (mH) Delta Part #
300 30 40 120 240 0.12 0.2 DR105AP106
370 37 50 146 292 0.087 0.145 DR146AP087
380V~460V/ 50~60Hz model VFDXXXVL43C-J series AC Input Reactor
Model KW HP
Rated Current Saturation Current 3% Reactor 5% Reactor 3% Input Reactor:
(Arms) (Arms) (mH) (mH) Delta Part#
110 11 15 21 42
1.01 1.683
DR024AP881
150 15 20 27 54
0.76 1.267
DR032AP660
185 18.5 25 34 68 0.639 1.066 DR038AP639
220 22 30 41 82 0.541 0.9 DR045AP541
300 30 40 60 120 0.405 0.675 DR060AP405
370 37 50 73 146 0.334 0.555 DR073AP334
450 45 60 91 182 0.267 0.445 DR091AP267
550 55 75 110 220 0.221 0.368 DR110AP221
750 75 100 150 300 0.162 0.27 DR150AP162
