Chapter 5 Parameters_VFD-B Series
Revision 10/2005, BE13, SW V4.08 5-39
02 - 11
aSource of the Auxiliary Frequency Command
Factory Setting: 00
Settings 00 Digital keypad (PU01) UP/DOWN keys or Multi-function Inputs UP/DOWN.
Last used frequency saved.
01 AVI 0 ~ +10VDC
02 ACI 4 ~ 20mA
03 AUI -10 ~ +10VDC
04 RS-485 serial communication (RJ-11). Last used frequency saved.
02 - 12
aCombination of the Master and Auxiliary Frequency Command
Factory Setting: 00
Settings 00 Master frequency + Auxiliary frequency
01 Master frequency - Auxiliary frequency
These three parameters (Pr.02-10~02-12) are enabled when Pr.02-00 or Pr.02-13 are set to 06. If they are
enabled, the frequency command will be determined by these parameters.
02 - 02
Stop Method
Factory Setting: 00
Settings 00 STOP: ramp to stop E.F.: coast to stop
01 STOP: coast to stop E.F.: coast to stop
02 STOP: ramp to stop E.F.: ramp to stop
03 STOP: coast to stop E.F.: ramp to stop
The parameter determines how the motor is stopped when the AC motor drive receives a valid stop
command or detects External Fault.
1. Ramp: the AC motor drive decelerates to Minimum Output Frequency (Pr.01-05) according to the
deceleration time and then stops.
2. Coast: the AC motor drive stops the output instantly upon command, and the motor free runs until it
comes to a complete standstill.
3. The motor stop method is usually determined by the characteristics of the motor load and how frequently
it is stopped.
