Chapter 11 Summary of Parameter SettingsME300
11-23
Pr. Explanation Settings Default
3: Continue operation after over-torque detection during
RUN
4: Stop after over-torque detection during RUN
0
06-10
Over-torque detection
level (motor 2)
10–250%
(100% corresponds to the rated current of the drive)
120
06-11
Over-torque detection
time (motor 2)
0.0–60.0 sec. 0.1
06-13
Electronic thermal relay
selection (motor 1)
0: Inverter motor (with external forced cooling)
1: Standard motor (motor with fan on shaft)
2: Disable
2
06-14
Electronic thermal relay
action time (motor 1)
30.0–600.0 sec. 60.0
06-15
Temperature level
over-heat (OH) warning
0.0–110.0
ºC 105.0
06-16 Stall prevention limit level 0–100% (refer to Pr.06-03–06-04) 100
06-17 Fault record 1 0: No fault record 0
06-18 Fault record 2 1: Over-current during acceleration (ocA) 0
06-19 Fault record 3 2: Over-current during deceleration (ocd) 0
06-20 Fault record 4 3: Over-current during constant speed (ocn) 0
06-21 Fault record 5 4: Ground fault (GFF) 0
06-22 Fault record 6 6: Over-current at stop (ocS) 0
Fault record 7 (Pr.14-70) 7: Over-voltage during acceleration (ovA)
Fault record 8 (Pr.14-71) 8: Over-voltage during deceleration (ovd)
Fault record 9 (Pr.14-72) 9: Over-voltage during constant speed (ovn)
Fault record 10 (Pr.14-73) 10: Over-voltage at stop (ovS)
11: Low-voltage during acceleration (LvA)
12: Low-voltage during deceleration (Lvd)
13: Low-voltage during constant speed (Lvn)
14: Low-voltage at stop (LvS)
15: Phase loss protection (orP)
16: IGBT over-heat (oH1)
18: TH1 open: IGBT over-heat protection error (tH1o)
21: Drive over-load (oL)
22: Electronic thermal relay protection 1 (EoL1)
23: Electronic thermal relay protection 2 (EoL2)
24: Motor PTC over-heat (oH3)
26: Over-torque 1 (ot1)
27: Over-torque 2 (ot2)
28: Low current (uC)
31: Memory read-out error (cF2)
