18
PMA-2000 IV R
Ref. No. Part No. Part Name RemarksRef. No. Part No. Part Name Remarks
SEMICONDUCTORS GROUP
TR401-404 275 0042 905 Transistor 2SK373(Y)TPE2
TR405 273 0442 004 Transistor 2SC4793 (Y)
TR406 271 0272 003 Transistor 2SA1837-Y
TR407 273 0442 004 Transistor 2SC4793 (Y)
TR408 271 0272 003 Transistor 2SA1837-Y
TR421-424 273 0281 919 Transistor 2SC2705 (Y)TPE6
TR425-428 275 0038 045
Transistor 2SK369 (BL)/(GR)-C
TR429-432 273 0281 919 Transistor 2SC2705 (Y)TPE6
TR433-436 271 0168 900
Transistor 2SA1145 (O)/(Y)TPE6
TR437,438 275 0069 001 Transistor 2SK215
TR439,440 275 0068 002 Transistor 2SJ78
TR451 269 0020 906 Transistor DTC114ES(10K-10K)T
D421-426 276 0432 903 Diode 1SS270A TE
D451,452 276 0432 903 Diode 1SS270A TE
ZD401,402 276 0483 907 Zener diode HZS30-1TD
ZD405,406 276 0645 907 Zener diode MTZJ18A T77
ZD421,422 276 0453 911 Zener diode HZS3B-2TD
ZD423,424 276 0460 904 Zener diode HZS5C-1TD
ZD451 276 0460 904 Zener diode HZS5C-1TD
LD421,422 393 9540 900 LED SLR-342MGTF7MN
RESISTORS GROUP
R401-404 241 2422 944 Carbon film 1 kohm 1/4W RD14B2E102JT(PSNB)
R421,422 241 2429 963 Carbon film 1 Mohm 1/4W RD14B2E105JT(PSNB)
R423,424 241 2420 988 Carbon film 220 ohm 1/4W RD14B2E221JT(PSNB)
R425,426 241 2426 908 Carbon film 33 kohm 1/4W RD14B2E333JT(PSNB)
R427,428 241 2426 940 Carbon film 47 kohm 1/4W RD14B2E473JT(PSNB)
R429-432 241 2422 944 Carbon film 1 kohm 1/4W RD14B2E102JT(PSNB)
R433,434 241 2421 929 Carbon film 330 ohm 1/4W RD14B2E331JT(PSNB)
R435,436 241 2422 902 Carbon film 680 ohm 1/4W RD14B2E681JT(PSNB)
R437,438 241 2429 963 Carbon film 1 Mohm 1/4W RD14B2E105JT(PSNB)
R439,440 241 2424 926 Carbon film 5.6 kohm 1/4W RD14B2E562JT(PSNB)
R441,442 241 2422 944 Carbon film 1 kohm 1/4W RD14B2E102JT(PSNB)
R443,444 241 2377 947 Carbon film 100 ohm 1/4W(NB) RD14B2E101JNBST
R445-448 241 2376 964 Carbon film 47 ohm 1/4W(NB) RD14B2E470JNBST
R449,450 241 2428 980 Carbon film 470 kohm 1/4W RD14B2E474JT(PSNB)
R451-454 244 2058 032 Metal oxide 47 ohm 1W(NB) RS14B3A470JNBS(RSFSV)
R457,458 241 2420 904 Carbon film 100 ohm 1/4W RD14B2E101JT(PSNB)
F401,402 241 2387 940 Carbon film 4.7 ohm 1/4W(NB) RD14B2E4R7JT(NB)
CAPACITORS GROUP
C401,402 254 4562 701 Electrolytic 47uF/100V CE04W2A470MC(ARS/2)
C405,406 255 4256 955 Polypropylene film 0.01uF/100V CQ93P2A103JT(NH2)
C407,408 254 4557 952 Electrolytic 47uF/50V CE04W1H470MT(RFS)
C409,410 254 4558 728 Electrolytic 470uF/50V CE04W1H471MC(RFS)
C411,412 255 4239 707 Polypropylene film 0.047uF/100V CQ93P2A473JC(NH)
C413,414 254 4557 952 Electrolytic 47uF/50V CE04W1H470MT(RFS)
C415,416 254 4558 702 Electrolytic 100uF/50V CE04W1H101MC(RFS)
C421,422 255 4251 976 Polypropylene film 10pF/100V CQ93P2A101JT(NH2)
C423,424 254 4557 936 Electrolytic 10uF/50V
CE04W1H100MT(RFS)
C425,426 255 4256 955 Polypropylene film 0.01uF/100V CQ93P2A103JT(NH2)
C427-430 254 4557 923 Electrolytic 4.7uF/50V
CE04W1H4R7MT(RFS)
C431,432 255 4250 977 Polypropylene film 39pF/100V CQ93P2A390JT(NH2)
C433-436 255 4255 972
Polypropylene film 4700pF/100V CQ93P2A472JT(NH2)
C439,440 255 4256 955
Polypropylene film 0.01uF/100V CQ93P2A103JT(NH2)
C441-444 254 4558 702 Electrolytic 100uF/50V CE04W1H101MC(RFS)
C451 254 4558 715 Electrolytic 220uF/50V CE04W1H221MC(RFS)
C453 254 4558 715 Electrolytic 220uF/50V CE04W1H221MC(RFS)
C455,456 255 4250 993 Polypropylene film 47pF/100V CQ93P2A470JT(NH2)
C461,462 254 4313 934 Electrolytic 47uF/50V
CE04W1H470MT(ASF)
OTHER PARTS GROUP Q'ty
CW055 203 8468 036 5P EH-SCN Connector cord 1
CW056 203 8468 049 5P EH-SCN Connector cord 1
CW931 203 5179 027 3P SCN-SCN Connector cord 1
CX057 205 0278 055 5P EH Connector base (BK) 1
CX103 205 0502 006 10P EH Connector base (RD) 1
CY031 205 0653 036 3P VH Connector base 1
RL401,402 214 0127 003 Relay (RY-12W) 2
ST401-403  Style pin 3
471 3304 028 Screw 3X8 CBS-B 4
 Radiator 4
1U-3433 FLAT AMP UNIT ASS'Y
