PMA-2000 IV R
Rear Panel
1. Remove 5 screws
6
, 6 screws
7
and 2 screws
8
.
2. Detach the Rear Panel in the arrow direction.
Heat Sink
Ass'y
Heat Sink Ass'y
Remove 2 screws
9
and detach the Heat Sink Ass'y in the
arrrow direction.
Rear Panel
Bottom Plate
Remove 24 screws
5
and detach it in the arrow direction.
Bottom Plate
9
6
7
7
8
5
