PMA-2000 IV R
Ref. No. Part No. Part Name Remarks Q'ty
83 461 0501 005 Rubber sheet 2
84 412 2814 015 Card spacer (L=14) 1
85 417 0540 205 CU plate 2
86 477 0096 007 Push rivet G2A,G1C,G1H 8
87 415 0680 017 Spacer G2A 1
88 461 0550 085 Rubber pad G2A 1
89 415 0847 009 PVC sheet G2A,G1C,G1H 1
90 513 1581 008 Serial No.sheet 1
91 462 0089 012 Bush 2
92 414 0958 005 Shield plate (A) 1
93 443 9015 002 P.W. spacer 4
94 412 4715 002 C. holder 1
95 441 1795 010 Plate (T/C) 1
96 412 4917 017 Shield plate 1
97 415 0860 002 Spacer 1
A 203 4930 021 3P VH-VH Connector cord CN022 1
B 203 5161 006 3P VH-VH Connector cord CN031 1
C 203 4872 037 3P KR-KR ribbonN 350 CN033 1
D 203 4871 096 3P KR-KR ribbon 250 CN035 1
E 203 6386 039 4P KR-KR ribbon 350 CN041 1
F 203 8356 009 5P EH-EH Connector cord CN051 1
G 203 8499 005 5P PH-PH Connector cord CN052 1
H 203 8342 039 5P KR-KR ribbon 350 CN053 1
I 203 8465 000 5P EH-EH Connector cord CN054 1
J 203 8439 036 5P EH-EH Connector cord CN057 1
K 204 0519 009 6P EH-EH Connector cord CN061 1
L 204 0379 032 6P KR-KR ribbon 350 CN062 1
M 204 2554 004 10P KR-KR ribbon 550 CN102 1
N 204 2921 006 10P EH-EH Connector cord CN103 1
O 204 6351 041 11P KR-KR ribbon 375 CN111 2
P 001 0202 021 Vinyl wire for AC inlet 1
Q 001 0202 034 Vinyl wire for AC inlet 1
R 001 0166 086 Vinyl wire for foil side 2
S 001 0197 055 Vinyl wire Red 18
T 001 0197 068 Vinyl wire Blue 1
445 8004 007 Wire clamper 10
203 5205 001 3P contact ass'y 2
415 0767 011 UL tube (16) BK 1
475 3201 000 3TWB (ZN) 1
203 0530 014 1P contact ass'y 2
415 0695 015 UL tube 2
445 8004 007 Wire clamper 95
445 0048 003 Cord holder (L76) 4
415 0847 009 PVC sheet 14
513 3815 002 Fuse caution label 1
513 3816 001 Fuse caution label 1
20
Ref. No. Part No. Part Name Remarks Q'ty
PARTS LIST OF EXPLODED VIEW
Ref. No. Part No. Part Name Remarks Q'ty Ref. No. Part No. Part Name Remarks Q'ty
1 1U-3432B Power amp P.W.B. unit Ass'y G1C,G1H 1
1U-3432A Power amp P.W.B. unit Ass'y G2A 1
1-1 Power amp unit (L)
1-2 Power amp unit (R)
1-3 Control unit
1-4 P.LED unit
1-5 S.direct switch unit
1-6 P.switch unit
1-7 Main VR. unit
1-8 AC outlet unit
1-9 Pre out unit
2 1U-3130H Input P.W.B. unit Ass'y
2-1 Input unit
2-2 Protector unit
2-3 Power supply unit
2-4 F. SW unit (R)
3 1U-3433 Flat amp P.W.B. unit Ass'y 1
4 206 1015 016 Fuse 1.25A (T) F108,G2A 1
206 1046 027 Fuse 5A KEU 1
5 206 1015 016 Fuse 1.25A (T) F109,G2A 1
206 1046 027 Fuse 5A KEU 1
6 204 8480 004 Head phone jack (SW) JK501 1
7 214 0195 006 Relay FTR-F1 RL501,502 2
8 212 1176 002 Power switch S101 1
9 212 1157 005 1P Push switch S201 1
10 233 6257 007 Power trans, mini G1C,G1H,G2A 1
233 6267 007 Power trans, mini KEU 1
11 211 0798 103 Variable resistor 100kohm VR201 (BALANCE) 1
12 211 0834 012 Variable resistor 10kohm VR202 (TREBLE) 1
13 211 0834 009 Variable resistor 30kohm VR203 (BASS) 1
14 211 0873 002 Variable resistor 30kohm VR351 (VOLUME) 1
15 203 3975 003 AC outlet G2A 1
203 3974 004 AC outlet KEU 1
16 214 0195 006 Relay FTR-F1 RL501,502 2
17 212 4331 006 Slide switch (4-6) remote S301 1
18 212 4728 004 1P Push switch S701 (MM/MC) 1
19 212 0407 002 Rotaly switch (SRRM-12) S901 (INPUT SELECTOR) 1
20 204 8530 006 4P Pin jack JK301-304 4
21 204 8531 005 2P Pin jack (C-GND) JK305 1
22 411 1341 515 Front chassis 1
23 445 0048 016 Cord holder (L50) 1
24 411 1346 248 Trans chassis 1
25 462 0089 054 Bush 1
26 105 1339 075 Back panel G1C 1
105 1339 091 Back panel G1H 1
105 1339 062 Back panel G2A 1
105 1411 003 Back panel KEU 1
27 205 1014 218 4P Terminal ass'y 2
28 412 4141 003 Trans bracket 1
29 415 9092 017 Teflon plate (PT) 2
30 513 3457 004 Trans label (D) 2
31 462 0089 025 Bush 3
32 205 0071 016 Terminal ass'y 1
33 477 0018 014 Washer (P-87) D10 2
34 414 0765 311 Shield plate 1
35 412 4390 016 TC bracket 2
36 415 9016 019 P.C.B holder 4
37 412 4112 113 P.W.B bracket (A) 1
38 203 3970 008 AC inlet 1
39 105 1197 644 Bottom cover 1
40 212 1147 002 Slide switch S202 1
41 146 2088 106 Foot ass'y 4
146 2088 119 Foot ass'y KEU 4
42 233 6332 000 Power trans G1C,G1H 2
233 6330 002 Power trans G2A 2
233 0537 005 Power trans KEU 2
43 415 9032 006 P.C.B holder (T) 4
44 254 6204 041 Electrolytic 12000uF/71V CE62W==123M 2
45 417 0571 119 Power radiator (R) 1
46 275 0105 004 Transistor 2SK2967 TR521-524 4
47 415 0234 007 Insulating sheet 4
48 412 4127 014 P.W.B bracket (B) 4
49 412 4387 016 Radiator bracket (R) 1
50 412 4114 111 Radiator bracket (B) 1
51 417 0571 106 Power radiator (L) 1
52 412 4386 017 Radiator bracket (L) 1
53 412 4113 112 Radiator bracket (A) 1
55 412 4388 015 Support bracket (L) 1
56 144 2510 296 Front panel ass'y 1
144 2807 006 Front panel ass'y KEU 1
57 212 4799 004 Rotary remote switch (REC OUT SELECTOR) 1
58 441 1780 216 Plate (M) 1
59 441 1781 202 Plate (F) 1
60 113 9303 101 Power knob ass'y 1
113 9303 114 Power knob ass'y KEU 1
61 112 0780 128 Knob (M) ass'y 1
112 0780 115 Knob (M) ass'y KEU 1
62 112 9125 108 Knob ass'y (F) 1
112 9125 137 Knob ass'y (F) KEU 1
63 112 0787 008 Knob (MARU) ass'y 4
112 0787 011 Knob (NARU) ass’y KEU 4
64 412 4389 014 Support bracket (R) 1
65 102 0574 133 Top cover 1
102 0574 159 Top cover KEU 1
66 461 9036 005 Spacer 2
67 441 1795 007 Plate (T/C) 1
69 209 0325 007 Short pin 2
70 206 1015 087 Fuse (4.0A) F101 G1C,G1H,G2A 1
206 1046 043 Fuse (10A) KEU 1
71 415 9080 003 Teflon spacer 7
72 412 4141 045 Trans bracket 1
73 475 3201 000 3 TWB 1
74 415 0809 005 Washer 12
76 475 1130 005 3 Washer 2
77 441 1890 203 Plate (RD) 2
79 113 9304 207 Push knob ass'y 1
113 9304 210 Push knob ass'y KEU 1
81 415 9093 003 Teflon washer (VR) 1
SCREWS
101 473 7002 021 Screw 3X8 CBTS (S)-B 6
102 471 3803 011 Screw 4X65 CBS 6
103 473 7508 017 Screw 3X10 CBTS (P)-B 8
104 477 0263 018 3P.Swelling screw 11
477 0263 005 3P.Swelling screw KEU 14
105 477 0064 107 Fixing screw 10
106 473 7501 014 Screw 3X14 CBTS (P)-Z 14
107 473 7500 015 Screw 3X8 CBTS (P)-Z 2
108 473 7007 000 Screw 4X8 CBTS (S)-B 16
109 473 8007 038 Cup screw 3X14 2
110 473 7003 004 Screw 3X8 CFTS (S)-Z 13
111 470 0009 022 Screw 3X6 CPS (SW.W) ZNP 2
112 473 7500 028 Screw 3X8 CFTS (P)-Z 8
113 473 8007 025 Cup screw 3X8 1
114 473 7003 017 Screw 3X8 CFTS (S)-B 1
115 473 7007 013 Screw 4X10 CBTS (S) ZNB 1
116 471 3409 017 Screw 4X16 CBS 1
117 475 6008 006 4N 1
118 473 8034 098 Screw 3X10 CBTS(B)-B 1
119 473 7002 005 Screw 3X6 CBTS(S)-Z 1
Note: The symbol in the column "Remarks" indicate the following destinations.
G1C: China model G1H: Hong Kong model
G2A: Singapore model KEU: U.S.A. model
