PARTS LIST OF P.C.B. UNIT
sd
zParts for which "nsp" is indicated on this table cannot be supplied.
zPart indicated with the mark " ★ " is not illustrated in the exploded view.
zThe parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
1611E3 : U.S.A. & Canada model 1611E2 : Europe model 1611E1C : China model
591E3 : U.S.A. & Canada model 591EA : Australia model 1621E1C : China model
BK : Black model SP : Premium Silver model
PCB 7CH_AMP ASS'Y (1611E3 model)
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
Q401 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q403 00D2710318909 TR 2SA 2N5401S J520254010010S
Q404 00D9960018706 TR 2SD2390-Y J5032390Y0000S
Q405 00D2710318909 TR 2SA 2N5401S J520254010010S
Q406 00D2730479909 TR 2SC 2N5551S J522255510010S
Q407,408 00D9600196302 TR KTA1268BL J5001268B0050S
Q409 963219003340S TR 2SC KTC3964 J502396400010S
Q410 00D9960018706 TR 2SB1560-Y J5011560Y0000S
Q412 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q413 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q415 00D2710318909 TR 2SA 2N5401S J520254010010S
Q416 00D9960018706 TR 2SD2390-Y J5032390Y0000S
Q417 00D9600196302 TR KTA1268BL J5001268B0050S
Q418 00D2730479909 TR 2SC 2N5551S J522255510010S
Q419,420 00D9600196302 TR KTA1268BL J5001268B0050S
Q421 963219003340S TR 2SC KTC3964 J502396400010S
Q422 00D9960018706 TR 2SB1560-Y J5011560Y0000S
Q424 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q425 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q427 00D2710318909 TR 2SA 2N5401S J520254010010S
Q428 00D9960018706 TR 2SD2390-Y J5032390Y0000S
Q430 00D2730479909 TR 2SC 2N5551S J522255510010S
Q431,432 00D9600196302 TR KTA1268BL J5001268B0050S
Q433 963219003340S TR 2SC KTC3964 J502396400010S
Q434 00D9960018706 TR 2SB1560-Y J5011560Y0000S
Q436 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q437 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q439 00D2710318909 TR 2SA 2N5401S J520254010010S
Q440 00D9960018706 TR 2SD2390-Y J5032390Y0000S
Q442 00D2730479909 TR 2SC 2N5551S J522255510010S
Q443,444 00D9600196302 TR KTA1268BL J5001268B0050S
Q445 963219003340S TR 2SC KTC3964 J502396400010S
Q446 00D9960018706 TR 2SB1560-Y J5011560Y0000S
Q448 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q449 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q451 00D2710318909 TR 2SA 2N5401S J520254010010S
Q452 00D9960018706 TR 2SD2390-Y J5032390Y0000S
Q454 00D2730479909 TR 2SC 2N5551S J522255510010S
Q455,456 00D9600196302 TR KTA1268BL J5001268B0050S
Q457 963219003340S TR 2SC KTC3964 J502396400010S
Q458 00D9960018706 TR 2SB1560-Y J5011560Y0000S
Q460 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
