PCB HDMI ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
U1001 nsp IC ADV7840 J040784005510S
U1002 231810090509S IC PQ018ENA1ZPH J126018010030S *
U1501 963239010410S IC ADV7511BSTZ-225 J040751100010S
U1703 00D2623077900 IC TC74VHCU04FT J040740405580S
U1706 236810062608S IC LC89058W-E J046890580020S
U1707 963243010640S
IC PAL/PLD
(EPM3032A-TC44)
963243010640S
U1901 nsp IC ADSP21367KSWZ2A1181 J080213675520S
U1902 963239010680S IC W9864G2IH-6 J001986460060S *
U1903 963243010650S
IC MEMORY FLASH
(EN29LV160BB-70TIP)
8952161100030
U2101 236810086505S IC AK5358BET-E2 J043535805520S *
U2102 236810073509S IC AK4358VQ-L J042435800010S
U2103-2106 963239001880S IC AZ4580M J121458000020S
U2501-2503 nsp IC EX3AV J048030030010S *
U2504,2505 231310009508S IC PQ033DNA1ZPH J126033010010S
U2506 234810015507S IC BU4248F J126424800010S
U2901 963239010560S IC TC74VHCT125AFT J040741255580S
U2902 234810014504S IC MC14094BDTR2G J040140940020S
U2903 00D2623437906 IC TC74VHCT244AFT J040742445540S
U2904 00D2623410907 IC TC74VHCT08AFT J040740800090S
U2905 00D2623444902 IC TC74VHC08FT J040740800280S
U3102 963243010620S
IC CPU MICRO PROCESSR
(5F64169DFD)
8952161100010
U3103 246810026500S R1EX24256ASAS0A J000242565550S
U3301 963243010670S
IC CPU MICRO PROCESS
(R5F3650KNFB)
8952161100020 *
Q1001 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q1002 00D9600285006 TR KRC104S (ND) J522104S00210S
Q1003 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q1004 00D9600285006 TR KRC104S (ND) J522104S00210S
Q1005 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q1006 00D9600285006 TR KRC104S (ND) J522104S00210S
Q1007 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q1008,1009 00D9600285006 TR KRC104S (ND) J522104S00210S
Q1302 00D2750110905 SEMI HN1K02FU J543102000020S
Q1501 00D9630120704 TR KRA102S(PB) J520010200210S
Q1502 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q1901 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q1902 00D9630120704 TR KRA102S(PB) J520010200210S
Q2509-2514 00D9630121402 TR KRA104S J520010400210S
Q2517-2522 963219004200S CHIP FDC608PZ P-CH J543608000010S
Q2523-2524 00D2710326904 TR 2SA 2SA1954 J520195405510S
Q2525 963209011260S D,SWITCHING DAN202U K005020200200S
Q2526-2527 00D2710326904 TR 2SA 2SA1954 J520195405510S
Q2528-2529 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q2531-2532 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q2533 00D9630121509 TR KTC3875S J522038750210S
Q2536 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q2537 00D9600285006 TR KRC104S (ND) J522104S00210S
Q2540 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q2541 00D9600285006 TR KRC104S (ND) J522104S00210S
NOTE :
When update Firmware,
please confi rm a last
version in SDI.
Use the service board
after updating it.
