PCB FRONT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC100 963239001880S IC AZ4580M J121458000020S
z
IC101 00D9600195808 IC ICP-N15 J120001500030S
IC102 963239001880S IC AZ4580M J121458000020S
Q100,101 00D9630121509 TR KTC3875S J522038750210S
Q102 00D9600133103 TR KSA916Y J5000916Y0050S
Q106 00D9600285006 TR KRC104S (ND) J522104S00210S
Q107,108 00D2710305909 SEMI KTA1504S J520015040150S
Q109 00D9630121402 TR KRA104S J520010400210S
Q112-113 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
D100,101 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D102,103 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D111-114 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D118,119 00D9630355401 D,SWITCHING KDS4148U K005041480030S
ZD100 00D9600095500 D,ZENER MTZJ5.1B K06005R144520S
ZD101 00D9600095801 D,ZENER MTZJ6.8B K06006R844520S
ZD102 00D9630046202 D,ZENER MTZJ18B K06018R044520S
ZD103 00D9630219903 D,ZENER MTZJ16B K06016R044520S
ZD104,105 00D9600095500 D,ZENER MTZJ5.1B K06005R144520S
LED101 963262010460S LED SIR-341ST3F 3PI 1611E3 K505341300010S
LED103 00D9630366108 LED BL-BEG204-L 5PI K500052004010S
RESISTORS GROUP
R127 00D9639006272 R,FIXED RSD-R1-1WJ-4.7 N113135647920S
CAPACITORS GROUP
C100 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C101 nsp C,FILM 0.1UF-J/100V D02010406C060S
C103 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C104 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C105 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C106 nsp C,CERAMIC 100PF-J/50V D010101167160S
C107 nsp C,CERAMIC COG82PF-J/50V D010820167160S
C108 nsp C,FILM 0.047UF-J/100V D02047306C060S
C109 nsp C,FILM 0.1UF-J/100V D02010406C060S
C110 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C111 nsp C,CERAMIC 1UF-Z/50V D011105597160S
C112 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C113 90M-OF100250R C,FILM 0.1UF-K/250V D02010407H080S
C114 nsp C,CERAMIC 330PF-J/50V D010331167160S
C115 nsp C,CERAMIC0.047UF-K/25V D011473774161S
C116 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C117 00D9630157900 C,ELECT 470UF-M/63V D040471088000S
C118 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C119 nsp C,FILM 0.1UF-K/250V D02010407H080S
