Symptom Cause Countermeasure Page
“CHECK SR
TUNER” is
displayed in the
SIRIUS mode.
• The Sirius Tuner unit is not
connected.
• Check that the connections are
correct.
14
“ANTENNA
ERROR” is
displayed in the
SIRIUS mode.
• If the Sirius Tuner is not
connected, it will be broken.
• Check that the connections are
correct.
14
“NO SIGNAL” is
displayed in the
SIRIUS mode.
• The signal cannot be received. • Reposition your SiriusConnect
Home Tuner antenna.
37
“INVALID
CHANNEL” is
displayed in the
SIRIUS mode.
• Channel is not present. • Select another channel. 37
“NO CH
AVAILABLE” is
displayed in the
SIRIUS mode.
• Even searching categories,
if none of the channels are
present, the “Parental Lock” is
on (locked).
• Please search for other
categories.
37
“ACQUIRING” is
displayed in the
SIRIUS mode.
• The selected channel is not
currently broadcasting.
• Displays while SiriusConnect
Home Tuner is connected.
• Select another channel. 37
“Call SIRIUS”z
is displayed in the
SIRIUS mode.
• Channels are not subscribed to. • If you subscribe to the channel,
you can receive the channel.
–
“SUB UPDATED”
is displayed in the
SIRIUS mode.
• While updating contract
information.
– –
“Code? [ ]” is
displayed in the
SIRIUS mode.
• Selected channels are locked. • Please insert pass word (4 digits)
into “[ ]”.
25
GSIRIUS Satellite RadioH
z : After scroll displays “Call 888-539-
....
” twice, displays “Call SIRIUS”.
n
Audio section
• Power amplifier
Rated output:
Front (A, B):
75 W + 75 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08 % T.H.D.)
110 W + 110 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Center:
75 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08 % T.H.D.)
110 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Surround:
75 W + 75 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08 % T.H.D.)
110 W + 110 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Output connectors: Front: A or B
16 ~ 16 Ω/ohms
A + B
12 ~ 16 Ω/ohms
Center, Surround:
16 ~ 16 Ω/ohms
• Analog
Input sensitivity / Input impedance:
200 mV / 47 kΩ/kohms
Frequency response:
10 Hz ~ 100 kHz — +1, –3 dB (DIRECT mode)
S/N:
98 dB (IHF-A weighted, DIRECT mode)
n
Video section
• Standard video connectors
Input / output level and impedance:
1 Vp-p, 75 Ω/ohms
Frequency response:
5 Hz ~ 10 MHz — +1, –3 dB
• S-Video connectors
Input / output level and impedance:
Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
C (color) signal — 0.286 Vp-p, 75 Ω/ohms
Frequency response:
5 Hz ~ 10 MHz — +1, –3 dB
• Color component video connectors
Input / output level and impedance:
Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
P
B / CB signal — 0.7 Vp-p, 75 Ω/ohms
P
R / CR signal — 0.7 Vp-p, 75 Ω/ohms
Frequency response:
5 Hz ~ 30 MHz — +0, –3 dB
n
Tuner section [FM] [AM]
(note: µV at 75 Ω/ohms, 0 dBf = 1 x 10
-15
W)
Receiving Range: 87.5 MHz ~ 107.9 MHz 520 kHz ~ 1710 kHz
Usable Sensitivity: 1.0 µV (11.2 dBf) 18 µV
50 dB Quieting Sensitivity: MONO 1.6 µV (15.3 dBf)
STEREO 23 µV (38.5 dBf)
S/N (IHF-A): MONO 77 dB
STEREO 72 dB
Total harmonic Distortion (at 1 kHz): MONO 0.15 %
STEREO 0.3 %
n
General
Power supply: AC 120 V, 60 Hz
Power consumption:
3.9 A
0.3 W (Standby)
Maximum external dimensions:
434 (W) x 171 (H) x 377 (D) mm (17-3/32” x 6-47/64” x 14-27/32”)
Weight: 10.8 kg (23 lbs 13 oz)
n
Remote control unit (RC-1104)
Batteries: R6/AA Type (two batteries)
Maximum external dimensions:
52 (W) x 243 (H) x 21 (D) mm (2-3/64” x 9-9/16” x 53/64”)
Weight: 184 g (Approx. 6.5 oz) (including batteries)
z For purposes of improvement, specifications and design are subject to change without notice.
Specifications
Getting Started Connections Setup Playback Remote Control Information Troubleshooting
ENGLISH
Specifications
