When 7.1-channel speakers are installed using
surround back speakers
.
z
1
z
2
z
3
FL
SW
C
SL
SBL
FR
SR
SBR
Listening
position
z
1 22° - 30°
z
2 90° - 110°
z
3 135° - 150°
0
When using a single surround back speaker, place it directly behind the listening
position.
o
When 5.1-channel speakers are installed
.
z
1
z
2
FL
SW
C
SL
FR
SR
z
1 22° - 30°
z
2 120°
