Example connections when using front Dolby Atmos Enabled speakers
This 7.1-channel surround system is the same as a basic 5.1-channel system but with front Dolby Atmos Enabled speakers.
.
C
SW
FL
FR
SL
SR
FDL
FDR
0
Set “Assign Mode” to “Front Dolby” in the menu. (
v
p. 184)
.
FDR
FDL
SW
FL
FR
C
SR
SL
