Denon AVR-S970H User Manual

Displaying your desired video during
audio playback (Video Select)
This unit can display video from a different source on TV during audio
playback. You can set this for each input source.
n
Supported input sources:
CD
z
/ Tuner / HEOS Music / Phono
z
This cannot be set when HDMI connector is assigned.
1
Press OPTION.
An option menu screen is displayed.
0
When the input source is “HEOS Music”, an option menu for
online music is displayed. Select “AVR Options…”, then press
ENTER.
2
Use cursor Up/Down to select “Video Select”, then
press ENTER.
The “Video Select” screen is displayed.
3
Use cursor Left/Right to select the Video Select mode.
Off
(Default):
Disable Video Select mode.
On: Enable Video Select mode.
4
If you selected “On” in step 3, press cursor Down and
select “Source”.
5
Use cursor Left/Right to select the input source for
video you want to play back, then press ENTER.
0
“Video Select” settings are stored for each input source.
Contents Connections Playback Settings Tips Appendix
114
Front panel Display Rear panel Remote Index

Denon AVR-S970H Specifications

General

Receiver type	-
Pre-out channels	0.2
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	85 W
HDMI in	6
Audio (L/R) in	4
USB ports quantity	1
Digital audio coaxial in	0
Digital audio optical in	2
Audio (L/R) out	7
Audio formats supported	AAC, ALAC, FLAC, MP3, WAV, WMA
Supported radio bands	AM, FM
Optical drive included	No
Display	VFD
HDCP version	2.3
Product color	Black
Audio decoders	DTS Virtual:X, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Volume control	Rotary
Number of products included	1 pc(s)
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W
Package weight	11500 g

Weight and Dimensions

Depth	341 mm
Width	434 mm
Height	167 mm
Weight	9500 g
