Denon AVR-S970H User Manual

o
Surround
Set the presence and size of the surround speakers.
Large:
Use a large speaker that can adequately
play back very low bass frequencies.
Small
(Default):
Use a small speaker that has inadequate
playback capacity for very low bass
frequencies.
None:
Select when the surround speakers are
not connected.
0
When “Surround” is set to “None”, “Surround Back”, “Surround Dolby” and
“Back Dolby” are automatically set to “None”.
o
Surround Back
Set the presence, size and number of surround back speakers.
Large:
Use a large speaker that can adequately
play back very low bass frequencies.
Small
(Default):
Use a small speaker that has inadequate
playback capacity for very low bass
frequencies.
None:
Select when the surround back speakers
are not connected.
2 spkrs
(Default):
Use two surround back speakers.
1 spkr:
Use only one surround back speaker.
Connect to the L terminal to SURROUND
BACK when this setting is selected.
0
When “Surround Back” is set to “None” or “1 spkr”, “Back Dolby” is
automatically set to “None”.
Contents Connections Playback Settings Tips Appendix
189
Front panel Display Rear panel Remote Index

Denon AVR-S970H Specifications

General

Receiver type	-
Pre-out channels	0.2
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	85 W
HDMI in	6
Audio (L/R) in	4
USB ports quantity	1
Digital audio coaxial in	0
Digital audio optical in	2
Audio (L/R) out	7
Audio formats supported	AAC, ALAC, FLAC, MP3, WAV, WMA
Supported radio bands	AM, FM
Optical drive included	No
Display	VFD
HDCP version	2.3
Product color	Black
Audio decoders	DTS Virtual:X, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Volume control	Rotary
Number of products included	1 pc(s)
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W
Package weight	11500 g

Weight and Dimensions

Depth	341 mm
Width	434 mm
Height	167 mm
Weight	9500 g
