Denon AVR-X2100W User Manual

Radio Text
RT allows RDS stations to send text messages that appear on the display.
“Radio text” appears on the display when radio text data is received.
1
Press OPTION when the input source is “Tuner”.
The option menu screen is displayed.
2
Use ui
to select “Radio text”, then press ENTER.
3
Use o p to select “On”, then press ENTER.
0
While receiving an RDS broadcast station, the text data
broadcast from the station is displayed.
0
If no text data is being broadcast, “NO TEXT DATA” is displayed.
Changing the tune mode (Tune Mode)
You can change the mode for tuning into FM and AM broadcasts. If you
cannot tune in automatically with “Auto” mode, change the mode to
“Manual” and tune in manually.
1
Press OPTION when the input source is “Tuner”.
The option menu screen is displayed.
2
Use ui to select “Tune Mode”, then press ENTER.
3
Use o p to select the tune mode, then press ENTER.
Auto:
Automatically search for and tune to a receivable radio
station.
Manual:
Manually change the frequency one step at a time each
time the button is pressed.
Contents Connections Playback Settings Tips Appendix
74
Front panel Display Rear panel Remote Index

Denon AVR-X2100W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	8
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	167 mm
Weight	9700 g
