Denon AVR-X2500H Service Manual

3-4. Operation Info Mode
3-4.1. Actions
This mode enables the unit to display the accumulated operating time, power On count and each
protection count.
3-4.2. Starting up
AVR-X2500H
• While holding down buttons "
ZONE2 SOURCE
", "
DIMMER
" and "
STATUS
" simultaneously, press the
power button to turn on the power.
AVR-S940H
• While holding down buttons "
TUNER PRESET CH +
", "
TUNE -
" and "
TUNE +
" simultaneously, press
the power button to turn on the power.
Select the "
4. OP INFO
" using the "
TUNER PRESET CH +/-
" button, then press the "
STATUS
" button
then to conrm.
3-4.3. Operations
Press the "
STATUS
" button after starting up this device in Operation Info mode.
The following information is displayed in the following order.
(1) Accumulated operating time
OP Time ______H
↑ Time display
"
STATUS
"
(2) Power On time
P.On Time______
↑ Time display
"
STATUS
"
(3) DC / ASO Protection time
DC:___/ASO:___
"
STATUS
"
(4) Thermal Protection (A/B) count
THM A:___/B:___
"
STATUS
"
(5) Thermal Protection (E) count
THM E:___
"
STATUS
"
(6) Current Protection time
Current:___
"
STATUS
"
(Returns to normal display)
