Denon AVR-X2500H Service Manual

VIDEO DIAGRAM
Cb
Y
Cb
Y
V02
Cr
Cr
V01
V03
OUT
HDMI6
HDMI5
USB_Tx_Rx
TX+/-
RX+/-
VIN1
VIN3
VIN4
COMP1-Y
IN0
IN1
IN2
IN3
OUT0
OUT0
TMDS IN
TMDS IN
IN0
IN1
Cb
Y
OUT
TMDS OUTPUT
IN1
(DVD)
IN2
(GAME)
HDMI4
HDMI2
HDMI1
VIN2
VIN5
COMP2-Cr
COMP1-Cr
COMP2-Cb
COMP1-Cb
COMP2-Y
IN1
IN0
IN3
IN2
OUT1
OUT1
TMDS IN
TMDS IN
OSD
OUT
IN2
Cr
OUT
TMDS OUTPUT
HDMI7
HDMI3
FRONT USB
GND
DATA-
VBUS
DATA+
COMP2-Y
USB_VBUS_ON/OFF
LEGO_PCK
LEGO_VSYNCLEGO_VSYNC
LEGO VIDEO(24BIT)
TMDS OUT
CVBS IN
IN1
(CBL/SAT)
COMP2-Cr
COMP2-Cb
COMP1-Cr
COMP1-Cb
COMP1-Y
FRONT HDMI
INPUT SELECT
LEGO_HSYNC
LEGO_EN
HDMI2.0 RX
MN864788
(HDCP 2.2 : 4 INPUTS)
HDMI SWITCH
TMDS261B
A3R12E40DBF-8E
HDMI i/p Scaler_TX_OSD
ADV8003-8B
(AD55-058Z-0)
TMDS OUT
W25Q128FVFIG
MX25L3206EM2I
4K OSD
HDMI2.0 TX
MN864788
HDMI OUT2
HDMI OUT1
IN2
(Blu-ray)
RJ-45
Wi-Fi BT ANT
AD8195
BUFFER
HDMI2.0 RX
MN864788
(HDCP 2.2 : 4 INPUTS)
HDMI IN
A3R12E40DBF-8E
COMPONENT IN
LEGO
NETWORK MEDIA
MODULE
AVR_S940H / X2500H VIDEO DIAGRAM
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
50

Denon AVR-X2500H Specifications

General

HDMI in	8
Composite video in	2
Ethernet LAN (RJ-45) ports	1
AirPlay	No
Display	-
Sample rate	196 kHz
HDCP version	2.2
Product color	Black
Audio decoders	DSD, DTS-HD, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Volume control	Rotary
RS-232 interface	Yes
Connectivity technology	Wired & Wireless
Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	8 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	185 W
Power output per channel (20-20KHz@8 Ohm)	95 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	500 W
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Deezer, Napster, Pandora, SIRIUS Internet Radio, Spotify, Tidal, TuneIn, iHeartRadio
Supported graphics resolutions	3840 x 2160

Weight and Dimensions

Depth	340.3 mm
Width	434.3 mm
Height	167.6 mm
Weight	9389 g
