Contents
Connecting speakers 26
Connecting a TV 49
Connecting a playback device 53
Connecting an iPod or USB memory device to the USB port 57
Connecting an FM/AM antenna 59
Connecting to a home network (LAN) 61
Connecting an external control device 63
Connecting the power cord 65
NOTE
0
Do not plug in the power cord until all connections have been completed.
However, when the “Setup Assistant” is running, follow the instructions in the
“Setup Assistant” (page 8 in the separate “Quick Start Guide”) screen for making
connections. (During “Setup Assistant” operation, the input/output connectors do
not conduct current.)
0
Do not bundle power cords together with connection cables. Doing so can result in
noise.
o
Cables used for connections
Provide necessary cables according to the devices you want to
connect.
Speaker cable
.
Subwoofer cable
.
HDMI cable
.
Component video cable
.
Video cable
.
Coaxial digital cable
.
Optical cable
.
Audio cable
.
R
L
R
L
LAN cable
.
Contents Connections Playback Settings Tips Appendix
Connections
25
Front panel Display Rear panel Remote Index

Denon AVR-X3200W Specifications
