Denon AVR-X3200W User Manual

Discover the thrilling world of immersive surround sound with the
Denon AVR-X3200W A/V Receiver, which features Dolby Atmos
®
and DTS:X™ (via a future firmware update in late 2015) surround
decoding for the ultimate home theater experience. Full wireless con-
nectivity is provided by both Wi-Fi and Bluetooth, with dual antennas
that help ensure robust signal transmission and reception. Stream
your favorite music from Internet radio stations, Spotify Connect
®
or
local network storage, and use AirPlay™ or Bluetooth to stream di-
rectly from a smart device. Control is made easy by the Denon AVR
Remote app for iOS and Android™. Enjoy 4K Ultra HD video (includ-
ing full HDCP 2.2 support) even from low resolution sources, thanks
to the advanced video processor with upscaling power. And enjoy
dierent video or audio content in a second zone through the multi-
room/multi-source capabilities.
AVR-X3200W
POWERFUL 7.2CH A/V RECEIVER WITH WI-FI,
BLUETOOTH
®
, 3D AUDIO, FULL 4K ULTRA HD
SUPPORT AND MULTI-ZONE OPTIONS
usa.denon.com
ca.denon.com
AVR-X3200W
Product Information
7.2CH A/V SURROUND RECEIVER

Denon AVR-X3200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	5
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	vTuner
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	650 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	11300 g
