EXPLODED
EXPLODED
※Parts indicated by "nsp"on this table cannot be supplied. Part indicated by "@" mark is not illustrated in the exploded view.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
PCB GROUP
P1 nsp FRONT PCB ASS'Y E3 VOP12909H 1 *
P1 nsp FRONT PCB ASS'Y E2,E1C VOP12909I 1 *
P1-P2 - STANDBY PCB ASS'Y -1*
P1-P3 - PHONE PCB ASS'Y -1*
P4 9U6391027500S USB&BT PCB ASS'Y VOP12743D 1 *
P5 943189101720S MODULE, BLUETOOTH CNVMB8811C0BR1 1 *
P6 nsp MAIN PCB ASS'Y E3 VOP12741F 1 *
P6 nsp MAIN PCB ASS'Y E2 VOP12741G 1 *
P6 nsp MAIN PCB ASS'Y E1C VOP12741H 1 *
P6-P7 - PHONE WIRE GUIDE -1*
P6-P9 - TUNER PCB ASS'Y -1*
P6-P10 - VIDEO PCB ASS'Y -1*
P6-P13 - FRONT CABLE GUIDE -1*
P6-P14 - USB WIRE GUIDE -1*
P8 943639103030S
DIGITAL PCB ASS'Y
See PROCEDURE AFTER REPLACING THE PCB.
E3 VOP12913B 1 *
P8 943639103040S
DIGITAL PCB ASS'Y
See PROCEDURE AFTER REPLACING THE PCB.
E2,E1C VOP12913C 1 *
P11 nsp SMPS PCB ASS'Y E3 VOP12910H 1 *
P11 nsp SMPS PCB ASS'Y E2,E1C VOP12910I 1 *
P11-P12 - REGULATOR PCB ASS'Y -1*
OTHER PARTS GROUP
! P15 943101102380D TRANS , POWER AVR-S500BT/E3 E3 VLT5U056ZU 1
! P15 943101102390D TRANS , POWER AVR-X510BT/E1 E2 VLT5U056ZE 1
! P15 943101102400D TRANS , POWER AVR-X510BT/E1C E1C VLT5U056ZH 1
! P16 943641500540S AC INLET WIRE ASS'Y (2P,110MM) E2 CWZPM5003TW91AH 1
F1 943412100710D KNOB , VOLUME CBN1A263 1
F2 943446100590D PLATE , VOLUME KNOB CGX1A469 1
F3 943412101070D KNOB,SELECT CBN1A274 1
F4 943446100760D PLATE,SELECT KNOB CGX1A481 1
F5 943402106410S FRONT/SUB PANEL ASS'Y E3 VGW1A553EA 1 *
F5 943402106420S FRONT/SUB PANEL ASS'Y E2,E1C VGW1A553DA 1 *
F6 943416101490D WINDOW , FL E3 VGU1A462M 1
F6 943416101320D WINDOW E2,E1C VGU1A462N 1
F7 42141002400AD BADGE , DENON CGB1A254Z-V1 1
F8 943411101750D BUTTON , POWER CBT1A1167 1
F9 943423100510D INDICATOR , POWER CGL1A299A36 1
F10 943411103220D BUTTON , SOURCE E3 VBT1A1195 1
F11 943411103210D BUTTON , NETWORK E3 VBT1A1194 1
F12 943411101770D BUTTON , 10KEY VBT2A1164 1
F13 nsp HOLDER , BT VMH1A356 1
F14 nsp PLATE , EARTH USB VMC1A430 1
F15 nsp SPRING , KNOB CUS1A169 2 *
M1 nsp CHASSIS , BOTTOM VUA4A335 1
M2 nsp RUBBER VHG1A113 1
M3 nsp LABEL , BOTTOM VQB1A1243 1
M4 943407100020D FOOT CKL1A190 4
M5 00D9630214607 CUSHION FOOT VHG2A289 4
M6 nsp HEAT SINK , MAIN VMY1A409 1
M7 nsp HOLDER , PCB CHE170 2
M8 nsp BRACKET , SMPS VMD1A790
1
M9 nsp BRACKET , PCB VMD1A774 2
M10 nsp PANEL , REAR E3 VKF4A481Z 1 *
M10 nsp PANEL , REAR E2 VKF5A481Y 1 *
M10 nsp PANEL , REAR E1C VKF6A481X 1 *
M11 nsp BUSHING , AC CORD E3,E1C CHR1A028 1
M12 943403100570D CABINET , TOP VKC2A215K117 1
M13 nsp CUSHION SUPPORT VHG1A305 2
@ 943606502450D CARD CABLE(1.0mm, 10P, 60mm) CWC4F4A10A060A08 1
@ 943606502440D CARD CABLE(1.25mm,27p,200mm)
CWC5C4A27B200B10001
1
@ 943606502460D CARD CABLE(1mm, 09p, 80mm) CWC4F4A09A080B10 1
@ nsp TAPE, HEMELON VHS1A032 1
SCREW GROUP
S1 nsp SCREW VTB3+6JR 13
S2 nsp SCREW VTW3+6JR 2
S3 nsp SCREW VTBD3+6FFZR 13
S4 nsp SCREW VTB3+8JR 24
S5 nsp SCREW VTB3+8JFZR 5
S6 nsp SCREW VTBD3+8JFZR 19
S7 nsp SCREW VTW3+8JR 13
S8 nsp SCREW VTW3+12JR 2
S9 nsp SCREW CTBD4+8JFZR 6
S10 nsp SCREW , TRANS VHDR1A023R 4
S11 nsp SCREW , SPECIAL VHD4A012R 3
S12 nsp SCREW , SPECIAL VHD1A012ZR 15
S13 nsp SCREW VTWS3+10GR 1
S14 nsp SCREW VTB3+6FR 4
21
