Denon AVR-X540BT Service Manual

USB
USB PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied. Part indicated by "@" mark is not illustrated in the exploded view.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D1401 943202501230S DIODE, ZENER(5.1V/0.5W, SOD-123) CVDMM1Z525V1B 1
D1404 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D1405 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9010 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9011 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9012 963209003510S DIODE , RELIABLE ESD PROTECTION CVDCDS3C05HDMI1 1
D9013 963209003510S DIODE , RELIABLE ESD PROTECTION CVDCDS3C05HDMI1 1
D9014 963209003510S DIODE , RELIABLE ESD PROTECTION CVDCDS3C05HDMI1 1
D9015 963209003510S DIODE , RELIABLE ESD PROTECTION CVDCDS3C05HDMI1 1
IC101 943232100540S I.C , DUAL OPAMP(SOP-8P) CVINJM4580CG 1
IC901 943243102260D I.C , SYSTEM CONTROLLER(TQFP-128P) CVIBX8804 1
IC902 943246101120S I.C , 64M SDRAM CVIW9864G6KH-6 1
IC903 23671011050AS I.C , IPOD AUTHENTICATION FROM D&M
CVI23671011050AS_DM
1
IC904 943189101710S I.C, USB_BLUETOOTH(AVRS530BT,AVRX540BT) VVIANAM2406AV 1 *
IC905 943239101090S I.C , High side switch (TSSOP-B8) CVIBD82065FVJ-E2 1
IC906 943239100690S I.C , 2CH DAC(32BIT,384KHZ,TSSOP-20P) CVIPCM5100PWR 1
IC909 943231101880D IC, regulator(1.2V , SSOP5) CVIBU12TD3WG 1
IC910 943231102170S IC, regulator(3.3V , SSOP5) CVIBU33TD3WG 1
RESISTOR GROUP
R1027 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R1401 nsp RES, CHIP(1005/5%/56Kohm) CRJ06IJ563T 1
R1402 nsp RES, CHIP(1005/5%/100Kohm) CRJ06IJ104T 1
R1403 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R1404 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R1405 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R1406 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R1407 nsp RES, CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R1408 nsp RES, CHIP(1608/5%/56Kohm) CRJ10DJ563T 1
R1409 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R1411 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R9010 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R9012 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R9017 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9018 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R9019 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R9020 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R9022 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9023 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9024 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9026 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9028 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9029 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9030 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9031 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9032 nsp RES, CHIP(1005/5%/100Kohm) CRJ06IJ104T 1
R9033 nsp RES, CHIP(1005/5%/1Mohm) CRJ06IJ105T 1
R9034 nsp RES, CHIP(1005/5%/220ohm) CRJ06IJ221T 1
R9035 nsp RES, CHIP(1005/5%/220ohm) CRJ06IJ221T 1
R9036 nsp RES, CHIP(1005/5%/220ohm) CRJ06IJ221T 1
R9037 nsp RES, CHIP(1005/5%/220ohm) CRJ06IJ221T 1
R9038 nsp RES, CHIP(1005/5%/220ohm) CRJ06IJ221T 1
R9041 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R9042 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R9043 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R9044 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9045 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R9046 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R9047 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R9048 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R9049 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R9050 nsp RES, CHIP(1005/5%/470ohm) CRJ06IJ471T 1
R9051 nsp RES, CHIP(1005/5%/470ohm) CRJ06IJ471T 1
R9052 nsp RES, CHIP(1005/5%/470ohm) CRJ06IJ471T 1
R9053 nsp RES, CHIP(1005/5%/470ohm) CRJ06IJ471T 1
R9054 nsp RES, CHIP(1005/5%/470ohm) CRJ06IJ471T 1
R9055 nsp RES, CHIP(1005/5%/470ohm) CRJ06IJ471T 1
R9056 nsp RES, CHIP(1005/5%/470ohm) CRJ06IJ471T
1
R9057 nsp RES, CHIP(1005/5%/470ohm) CRJ06IJ471T 1
R9058 nsp RES, CHIP(1005/5%/470ohm) CRJ06IJ471T 1
R9059 nsp RES, CHIP(1005/5%/470ohm) CRJ06IJ471T 1
R9060 nsp RES, CHIP(1005/5%/470ohm) CRJ06IJ471T 1
R9061 nsp RES, CHIP(1005/5%/470ohm) CRJ06IJ471T 1
R9066 nsp RES, CHIP(1005/5%/560ohm) CRJ06IJ561T 1
R9067 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9068 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9069 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9070 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R9071 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R9072 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R9073 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R9074 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R9075 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R9076 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R9077 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R9078 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R9079 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9080 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9081 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9082 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9083 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9084 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9085 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9086 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R9088 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9089 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R9090 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R9091 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R9092 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R9093 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
RN901 nsp RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN902 nsp RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN903 nsp RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN904 nsp RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN905 nsp RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN906 nsp RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN907 nsp RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN908 nsp RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN909 nsp RES, CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
CAPACIITORS GROUP
C1401 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C1402 nsp CAP, SMD ELECT(50V/1uF) CCEC1HMVG1R0T 1
1
