FRONT

FRONT PCB ASS'Y

※Parts indicated by "nsp"on this table cannot be supplied. Part indicated by "@" mark is not illustrated in the exploded view.

※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.

NOTE:The symbols in the column Remarks indicate the following destinations.

E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model

BK : Black model SP : Premium Silver model

REF No. Part No. Part Name Remarks Q'ty New Ver

SEMICONDUCTORS GROUP

D1001 943203500730S DIODE, RECTIFIER, AXIAL CVD1N4007SL 1

D1003 943202501110S DIODE, ZENER, 1/2W, 6.8V CVDZJ6V8BL 1

D1005 943202501120S DIODE, ZENER, 1/2W, 39V CVDZJ39BL 1

D1012 943176010090S L.E.D,(GREEN/RED 5PI) CVDBLBJEGJ204L 1

Q1001 943219006820S T.R CVTKTC1027YT 1

Q1003 943214500020S T.R,2SC3052 CVT2SC3052 1

Q1004 943214500020S T.R,2SC3052 CVT2SC3052 1

Q1005 963212500030S T.R, ISA1530AC1 CVTISA1530AC1 1

Q1006 00D2690192902 T.R , CHIP , SOT-23 HVTKRC102S 1

Q1008 00D2690184907 T.R , CHIP , SOT-23 HVTKRA102S 1

Q1009 00D2690192902 T.R , CHIP , SOT-23 HVTKRC102S 1

Q1011 00D2690184907 T.R , CHIP , SOT-23 HVTKRA102S 1

Q1012 00D2690192902 T.R , CHIP , SOT-23 HVTKRC102S 1

Q1013 00D2690192902 T.R , CHIP , SOT-23 HVTKRC102S 1

Q1014 943219006820S T.R CVTKTC1027YT 1

Q1015 943219500200M T.R , CHIP , SOT-23 HVTKRC104S 1

Q1016 943214500020S T.R,2SC3052 CVT2SC3052 1

RESISTOR GROUP

R1001 nsp RES, CARBON(1/5W,1.8ohm,J) CRD20TJ1R8T 1

R1004 nsp RES, CARBON(1/5W,1.8ohm,J) CRD20TJ1R8T 1

R1005 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 1

R1006 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 1

R1007 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1

R1008 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 1

R1009 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 1

R1010 nsp RES, CHIP(1608/5%/39Kohm) CRJ10DJ393T 1

R1012 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1

R1013 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1

R1014 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1

R1015 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1

R1016 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1

R1017 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1

R1018 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1

R1019 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1

R1020 nsp RES, CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1

R1021 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1

R1025 nsp RES, CHIP(1608/5%/39Kohm) CRJ10DJ393T 1

R1026 nsp RES, CHIP(1608/5%/39Kohm) CRJ10DJ393T 1

R1030 nsp RES, CARBON(1/5W,10ohm,J) CRD20TJ100T 1

R1041 nsp RES, CHIP(1608/5%/1.2Kohm) CRJ10DJ122T 1

R1042 nsp RES, CHIP(1608/5%/1.2Kohm) CRJ10DJ122T 1

R1043 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1

R1046 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1

R1053 nsp RES, CHIP(1608/5%/10ohm) CRJ10DJ100T 1

R1057 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1

R1058 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1

R1059 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1

R1060 nsp RES, CHIP(1608/5%/10Kohm)

CRJ10DJ103T 1

R1061

nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1

R1067 nsp RES, CARBON(1/5W,10ohm,J) CRD20TJ100T 1

R1068 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

R1069 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1

R1071 nsp RES, CHIP(1608/5%/5.6Kohm) E3 CRJ10DJ562T 1

R1072 nsp RES, CHIP(1608/5%/3.3Kohm) E3 CRJ10DJ332T 1

R1073 nsp RES, CHIP(1608/5%/2.7Kohm) E3 CRJ10DJ272T 1

R1074 nsp RES, CHIP(1608/5%/1.5Kohm) CRJ10DJ152T 1

R1075 nsp RES, CHIP(1608/5%/1Kohm) E3 CRJ10DJ102T 1

R1075 nsp RES, CHIP(1608/5%/0ohm) E2,E1C CRJ10DJ0R0T 1

R1076 nsp RES, CHIP(1608/5%/5.6Kohm) E3 CRJ10DJ562T 1

R1077 nsp RES, CHIP(1608/5%/3.3Kohm) E3 CRJ10DJ332T 1

R1078 nsp RES, CHIP(1608/5%/2.7Kohm) E3 CRJ10DJ272T 1

R1079 nsp RES, CHIP(1608/5%/1.5Kohm) E3 CRJ10DJ152T 1

R1079 nsp RES, CHIP(1608/5%/0ohm) E2,E1C CRJ10DJ0R0T 1

R1080 nsp RES, CHIP(1608/5%/1Kohm) E3 CRJ10DJ102T 1

R1080 nsp RES, CHIP(1608/5%/0ohm) E2,E1C CRJ10DJ0R0T 1

R1081 nsp RES, CHIP(1608/5%/5.6Kohm) E3 CRJ10DJ562T 1

R1082 nsp RES, CHIP(1608/5%/3.3Kohm) E3 CRJ10DJ332T 1

R1082 nsp RES, CHIP(1608/5%/2.7Kohm) E2,E1C CRJ10DJ272T 1

R1083 nsp RES, CHIP(1608/5%/2.7Kohm) E3 CRJ10DJ272T 1

R1084 nsp RES, CHIP(1608/5%/1.5Kohm) CRJ10DJ152T 1

R1085 nsp RES, CHIP(1608/5%/1Kohm) E3 CRJ10DJ102T 1

R1085 nsp RES, CHIP(1608/5%/0ohm) E2,E1C CRJ10DJ0R0T 1

R1090 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

R1092 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

R1413 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1

R1414 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1

R1415 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1

R1416 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1

R1423 nsp RES, CARBON(1/5W,47Kohm,J) CRD20TJ473T 1

R1424 nsp RES, CARBON(1/4W,27Kohm,J) CRD25TJ273T 1

R1425 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT 1

R1426 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT 1

R1428 nsp RES, CHIP(1608/5%/220Kohm) CRJ10DJ224T 1

R1429 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1

R1430 nsp RES, CHIP(1608/5%/22Kohm) CRJ10DJ223T 1

CAPACIITORS GROUP

C1002 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1

C1003 nsp CAP, ELECT(50V/10uF)-S CCEA1HKS100T 1

C1004 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1

C1005 nsp CAP , ELECT(63V/100uF) CCEA1JH101E 1

C1006 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1

C1007 nsp CAP,METAL-FILM(100V/0.047uF) CCME2A473JXT 1

C1009 nsp CAP, CHIP(2012, 50V/0.1uF, X7R)_SAMSUNG CCUC1H104KCS 1

C1010 nsp CAP, ELECT(16V/47uF)-S CCEA1CKS470T 1

C1011 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C1013 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 1

C1014 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 1

C1015 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1

C1016 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1

C1017 nsp CAP,METAL-FILM(100V/0.047uF) CCME2A473JXT 1

C1019 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1

C1020 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1

C1038 nsp CAP, ELECT(16V/47uF)-S CCEA1CKS470T 1

C1039 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 1

C1054 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C1055 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C1065 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1

C1066 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C1067 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1

C1068 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C1071 nsp CAP, CHIP(1608, 50V/680pF, C0G)_SAMSUNG CCUS1H681JAS 1
