Denon DHT-S217 User Manual

Settings
Perform the below operations and settings as needed.
Sound mode
buttons
BASS
+, –
VOL
+, –
Selecting a sound mode
1
Press the sound mode button to select a sound mode.
When the button is pressed, the rightmost status LED blinks and the
sound mode changes. (v p. 9)
MOVIE:
Enjoy movie theater-like surround
sound.
NIGHT:
Compresses the dynamic range
(difference between loud and soft
sounds) to make audio easier to hear at
low volumes.
MUSIC:
Enjoy the full presence of a wide,
encompassing acoustic field.
DIALOG ENHANCER
LOW / MED / HIGH:
Adjust the volume of dialog in movies,
vocals in music, etc. so these can be
heard more easily. Can be set to 3
levels. Set this to the desired value.
PURE:
Enjoy sound that is faithful to the
original source.
NOTE
0
In pure mode, Dolby Atmos playback is not supported. If a Dolby Atmos signal is
input when in pure mode, the status LED displays the signal input as Dolby (other
than Atmos). (v p. 9)
Contents Connections Playback Settings Tips Appendix
27

Denon DHT-S217 Specifications

General

Audio decoders	Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby TrueHD
TV Sound Share	Yes
RMS rated power	- W
Audio output channels	2.1 channels
Woofer diameter	75 mm
Tweeter diameter	25 mm
Woofer diameter (imperial)	3 \
Tweeter diameter (imperial)	1 \
Subwoofer location	Built-in
Product color	Black
Wall mountable	-
HDMI in	1
Connectivity technology	Wireless
Power consumption (standby)	0.5 W
Number of products included	1 pc(s)

Weight and Dimensions

Depth	120 mm
Width	890 mm
Height	67 mm
Soundbar weight	3600 g
