Denon S-52 Service Manual

87
S-52/S-52DAB/S-32
PARTS LIST OF CD MECHANISM UNIT(S-52)
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Ref. No. Part No. Part Name Remarks Q'ty New
40A 00D9KA2A769 FGDVS202MS-LOADER-UNIT A2A769 1 *
40B 00D9KA2A770 FGDVS202MS TRAVERSE-ASSY A2A770 1 *
40C 00D9KA2A771 FGDVS202MS PWB-AS A2A771 1 *
40-1 nsp
M2 × 4 BIND S-TIGHT CR3
BCS04U3 3
40-2 nsp TOP-COVER C8P118 1
40-3 nsp SCW-DAMPER-CR3 C1H012 4
40-4 00D9KA2G734 DAMPER SI50 A2G734 4 *
40-5 00D9KC2P183 FFC 0.5-24º› L70-G C2P183 1
40-6 nsp MAIN-BASE A2P834 1
40-7 nsp PCB-SHAFT A2H073 4
40-8 nsp SENSOR-PCB-HF C8P046 1
40-9 00D9KECEL012 PT4800BCE00F ECEL012 2
40-10 nsp CNW-3P-PN C8G046 1
40-11 nsp M2.6X6 BIND-TYPE-BK-CR3 BDZ06K3 4
40-12 nsp SCW-DAMPER-CR3 C1H013 4
40-13 00D9KC2G083 DAMPER-IDLE C2G083 2
40-14 00D9KA2G643 DAMPER-SI25-LB A2G643 2
40-15 nsp M2.6X6 BIND-S-TIGHT-CR3 BDS06U3 4
40-16 nsp MECHA-BRACKET 4125413109 1
41 nsp MAIN CHASSIS 4112119102 1 *

Denon S-52 Specifications

General

RMS rated power	20 W
Connectivity technology	Wireless
Impedance	4 Ω
Interface	USB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Ethernet LAN	Yes
Product color	Black
Audio formats supported	AAC, MP3, WAV, WMA
Power requirements	100 - 240 V, 50/60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	37 W

Weight and Dimensions

Depth	226 mm
Width	380 mm
Height	126 mm
Weight	6700 g
