4.7 Setup Modes
The Setup Modes contain parameters which configure the instrument and affect how
the control functions. To access the Setup Modes from the Control Mode, press the
SCROLL key until the lower display reads Mod. Press the DOWN key, then press the
SCROLL key to view the different modes available. The following sections contain
instructions for accessing and using the various Setup Modes. To return to Control
Mode, press the SCROLL key until CtrL is displayed, then press the DOWN key.
If a mode is not enabled (see Section 10) it will not be displayed in the Setup Mode list.
Table 4-2 Setup Modes
MODE DISPLAY DESCRIPTION MANUAL
SECTION
Control CtrL Return to Control Mode 4
Tune tunE Contains PID tuning parameters 5
Alarm ALA Contains alarm parameters 6
Test tESt Provides testing parameters for outputs 7
Configuration ConF Contains parameters which control inputs and outputs 8
Calibration CAL Contains instrument calibration parameters 9
Enable EnAb Controls access to the various modes 10
PreTune Pre Turns the Pre-tune facility off and on 11
AutoTune Auto Turns the Auto-tune facility off and on 12
RaPIDTune rAP Turns the RaPID tune facility off and on 13
