DeWalt D25604 User Manual

4
ENGLISH
English (original instructions)
SDS MAX COMBINATION & CHIPPING HAMMERS
D25501, D25601, D25604, D25831
Congratulations!
You have chosen a
DeWALT
tool. Years of experience, thorough product development and innovation make
DeWALT
one of the most reliable partners for
professional power toolusers.
Technical Data
D25501 D25601 D25604 D25831
Voltage V
AC
230 230 230 230
UK & Ireland V
AC
230/115 230/115 230/115 230/115
Type 2 3 3 3
Frequency Hz 50 50 50 50
Power input W 1100 1250 1250 1250
No load speed min
-1
490 210–415 210–415 –
No load beats per-minute bpm 3300 1430–2840 1430–2840 1430–2840
Single impact energy (EPTA 05/2009) J 8 2–8 2–8 2–8
Total drilling range in concrete:
solid bits mm 12–40 12–45 12–45 –
core bits mm 40–90 40–100 40–100 –
Optimum drilling range in concrete:
solid bits mm 18–26 25–35 25–35 –
Chisel positions 18 18 18 18
Tool holder SDS Max SDS Max SDS Max SDS Max
Weight kg 6.15 6.8 6.9 6.1
Noise values and vibration values (triax vector sum) according to EN60745-2-6:
L
PA
(emission sound pressure level) dB(A) 94 94 94 93
L
WA
(sound power level) dB(A) 105 105 105 104
K (uncertainty for the given sound level) dB(A) 3 3 3 3
Drilling into concrete
Vibration emission value a
h, HD
= m/s
2
17.2 8.9 8.9 –
Uncertainty K = m/s
2
1.5 1.5 1.5 –
Chiselling
Vibration emission value a
h,Cheq
= m/s
2
12.4 7.1 7.1 12.1
Uncertainty K = m/s
2
1.5 1.5 1.5 1.5
The vibration emission level given in this information sheet has been
measured in accordance with a standardised test given in EN60745 and
may be used to compare one tool withanother. It may be used for a
preliminary assessment ofexposure.

WARNING: The declared vibration emission level represents the
main applications of thetool. However if the tool is used for different
applications, with different accessories or poorly maintained, the
vibration emission maydiffer. This may significantly increase the
exposure level over the total workingperiod.
An estimation of the level of exposure to vibration should also take
into account the times when the tool is switched off or when it is
running but not actually doing thejob. This may significantly reduce
the exposure level over the total workingperiod.
Identify additional safety measures to protect the operator from the
effects of vibration such as: maintain the tool and the accessories, keep
the hands warm, organisation of workpatterns.
EC-Declaration of Conformity
Machinery Directive
SDS Max Combination & Chipping Hammers
D25501, D25601, D25604, D25831
DeWALT
declares that these products described under Technical Data are
in compliance with:
2006/42/EC, EN60745-1:2009+A11:2010, EN60745-2-6:2010.
D25831
2000/14/EC Electrical concrete breaker (hand held) m </= 15kg, Annex VIII;
TÜV Rheinland LGA Products GmbH (0197), D-90431 Nürnberg, Germany
Notified Body IDNo.: 0197
Level of sound power according to 2000/14/EC (Article 12, Annex III, No. 10;
m </= 15 kg)
