Unpacking
• Remove all parts, boxes and skin packs from
the box.
Identifying the Hardware Parts
(fi g. B)
We recommend that you unpack and sort all
hardware parts.
15 Combination wrench
16 Box spanner 10 mm
17 Box spanner 13 mm
18 Hex key 5 mm
19 Hex key 8 mm
20 Wing nut M6
21 Flat washer M6
22 Bevel lock knob ø 50 mm
23 Coach bolt M6 x 20
24 Flat washer D9-27
25 Crosshead screw 3.5 x 9.5
26 Hex screw M6 x 16
27 Toothed washer D6.4
28 Coach bolt M6 x 16
29 Nut M6
30 Cable clamp
31 Hex screw M6 x 30
32 Belleville washer D6
33 Cap nut M6
34 Compression spring D6
35 Fence rail clamp knob ø 40 mm
36 Flat washer D6.6-18
37 Crosshead screw, countersunk 4.8 x 16
38 Wing nut
39 Half fillet screw M6 x 45
40 Medium nut M6
41 Washer D6-16
Required and Recommended Tools
Apart from the tools included with the machine, the
following tools are required:
- Flat blade screwdriver
- Crosshead screwdriver
- Ruler
- Set square
- Soft hammer (or regular hammer and block of
wood)
WARNING: Always use the correct type
and size of tool.
Mounting the Elevating Handle
(fi g. C1, C2)
Required hardware parts: 1 wing nut (20), 1 flat
washer (21) (fig. C1).
• Turn the motor frame assembly on its side as
shown (fig. C2).
• Place the elevating handle (11) onto the shaft
(51). Make sure that the flat side in the handle is
facing the flat side (52) on the shaft.
• Fix the handle using a washer (21) and nut (20).
Mounting the Motor Frame Assembly
to the table (fi g. D1–D4)
Required hardware parts: 2 lock knobs (22), 2
coach bolts (23), 2 flat washers (24), 3 Hex screws
(26), 3 toothed washers (27), 3 nuts (29), 8Belleville
washers (32), 8 cap nuts (33), 6 flat washers (36)
(fig. D1).
MOUNTING THE FRAME BRACKETS
• Put the saw table upside down on a worktable
as shown (fig. D2).
• Hold the motor frame assembly in position as
shown.
• While holding the motor frame in vertical
position with one hand, place the brackets (53)
over the studs (54).
• Mount the moveable guard (55) following the
instructions under Mounting the blade guard
assembly.
• Place a washer (32) and a nut (33) onto the end
of each of the studs.
• Tighten the nuts hand-tight.
MOUNTING THE BEVEL LOCK KNOBS
• While holding the motor frame assembly in
vertical position, place a washer (24) between
the brackets (53) and the edges on each end of
the motor frame (fig. D3).
• Align the washers with the square holes (56).
• Insert a coach bolt (23) into the holes.
• Place a bevel lock knob (22) onto the end of
each of the bolts.
• Tighten the knobs.
MOUNTING THE BEVEL STOPS
• Insert a screw (26) fitted with a washer (36) into
the slot on the left-hand side of the lock knob
(22) in the front bracket (53A) (fig. D4).
