Chapter 6
Reference 47
DB9 Pinouts
DB9
Pin
EIA-232
EIA-422/485
Full-Duplex
EIA-485 Half-
Duplex
1 DCD CTS- Not used
2 RxD RxD+ RxD+
3 TxD TxD+ TxD+
4DTR RTS- Not used
5GND GND GND
6 DSR RxD- RxD-
7RTS RTS+ Not used
8 CTS CTS+ Not used
9 NA TxD- TxD-
