9
EN
Americana and New Generation Refrigerators General Information
Diagnostics Table
Component Page
Burner Assembly 16
Climate Control Heater 16
Communication Wire Harness 16
Cooling Unit 17
Door Flapper (RM1350 model only) 17
Door Hinge 17
Doors 18
Electrode 18
Flue Baffle 19
Gas Valve 19
Heating Element 19
Ice Maker 20
Interior Light 20
Lower Control Module 21
Orifice 22
Re-Igniter 18
Relay (RM1350 model only) 18
Thermal Fuse 22
Thermistor 23
Thermocouple (Older Americana models only) 23
Thermo Fuse 23
Upper Control Module 24
Ventilator Fan/Switch 24
Water Valve 24
4 General Information
This section provides reference information on the
tooling, model identification, components, and
terminology associated with the different models.
I
The images used in this document are for reference
purposes only. Components and component
locations may vary according to specific product
models.
4.1 Tools and Materials
Dometic recommends that the following tools and
materials be used while servicing the refrigerators:
Recommended Tools
Flat-Bladed Screwdriver Phillips Head Screwdriver
Heat Gun Razor Knife
Insulated Needle Nose
Pliers
Substance Temperature
Thermometer
Multimeter - DC/AC
Amperage, AC/DC Voltage,
Millivolts, Ohms
Wrenches
U-Tube Manometer
4.2 Model Identification
Each refrigerator is manufactured with a data plate that
includes useful information like the model number,
product number, manufacturing number and serial
number. For most models, the data plate is located
inside the refrigerator near the top of the inside cabinet.
This section explains the breakdown of the model
identification numbers.
