579 & 595 Installation Instructions
SPECIFICATIONS
MODEL NOMINAL ELECTRICAL COMPRESSOR COMPRESSOR FAN MOTOR FAN MOTOR SCFM-HIGH TOTAL REFRIGERANT MINIMUM AC CIRCUIT INSTALLED MINIMUM
NO. CAPACITY RATING RATED LOAD LOCKED RATED LOAD LOCKED SPEED STATIC R-22 (OZ.) WIRE SIZE* PROTECTION WEIGHT GENERATOR
(BTU/HR) AMPS ROTOR AMPS ROTOR MAX/MIN MIN/MAX *** USER (POUNDS) SIZE**
COOLING AMPS AMPS “ W. C. SUPPLIED 1 UNIT/ 2 UNITS
57915.331 13,500 11.4 58.0 2.5 5.8 325 / 250 0.55 / 0.90 15.5 20 Amp 100 3.5 KW / 5.0 KW
57915.336 13,500 11.4 58.0 2.5 5.8 325 / 250 0.55 / 0.90 15.5 20 AMP 100 3.5 KW / 5.0 KW
57915.531 13,500 12.1 59.0 2.5 5.8 325 / 250 0.55 / 0.90 16.5 20 Amp 94 3.5 KW / 5.0 KW
57915.536 13,500 12.1 59.0 2.5 5.8 325 / 250 0.55 / 0.90 16.5 20 Amp 94 3.5 KW / 5.0 KW
57915.541 13,500 11.3 62.0 2.5 5.8 325 / 250 0.55 / 0.90 16.0 20 Amp 94 3.5 KW / 5.0 KW
57915.546 13,500 11.3 62.0 2.5 5.8 325 / 250 0.55 / 0.90 16.0 20 Amp 94 3.5 KW / 5.0 KW
57915.631 13,500 11.0 54.4 2.5 5.8 325 / 250 0.55 / 0.90 16.5 20 Amp 94 3.5 KW / 5.0 KW
57915.731 13,500 11.3 56.0 2.5 5.8 325 / 250 0.55 / 0.90 15.0 20 Amp 94 3.5 KW / 5.0 KW
59516.331 15,000 11.5 50.0 2.5 5.8 325 / 250 0.40 / 1.10 29.0 20 Amp 94 3.5 KW / 5.0 KW
59516.336 15,000 11.5 50.0 2.5 5.8 325 / 250 0.40 / 1.10 29.0 20 Amp 94 3.5 KW / 5.0 KW
59516.531 15,000 11.5 50.0 2.5 5.8 325 / 250 0.40 / 1.10 26.5 20 Amp 94 3.5 KW / 5.0 KW
59516.536 15,000 11.5 50.0 2.5 5.8 325 / 250 0.40 / 1.10 26.5 20 Amp 94 3.5 KW / 5.0 KW
59516.631 15,000 12.3 77.0 2.0 5.6 325 / 250 0.40 / 1.10 29.5 20 Amp 104 3.5 KW / 5.0 KW
115VAC,
60 HZ., 1PH.
12 AWG
Copper
up to 24’
* For wire lengths over 24 ft. consult the National Electric Code for proper sizing.
** Dometic Corporation gives GENERAL guidelines for generator requirements. These guidelines come from experiences people have had in actual applications
When sizing the generator, the total power usage of your recreational vehicle must be considered. Keep in mind generators lose power at high altitudes and
from lack of maintenance.
*** CIRCUIT PROTECTION: Time Delay Fuse or HACR Circuit Breakers Required.
