Dometic MasterFlush 8100 Series Installation Manual

6
Dometic 8100 Series MasterFlush ToiletSpecifications
4.2 Minimum System Requirements
4.3 Dimensions (g.
3
, page 2)
Ref. Dimension
A 18.375 in. / 467 mm
B 14.75 in. / 375 mm
C 18.375 in. / 467 mm
D 17 in. / 432 mm - seat height
E 14.875 in. / 378 mm
F 32 in. / 813 mm - seat lid up
Ref. Dimension
A 3.25 in. / 83 mm
B 3.25 in. / 83 mm
Ref. Dimension
A 15 in. / 381 mm
B 14.75 in. / 375 mm
C 18.375 in. / 467 mm
D 13.75 in. / 349 mm - seat height
E 14 in. / 356 mm
F 28 in. / 711 mm - seat lid up
Standard-height models
Dometic flush switch panel
(g.
4
, page 2)
Low-profile models
4 Specifications
4.1 Materials
Toilet: vitreous ceramic
Macerator pump body: glass-lled polypropylene
Dometic flush switch panel: powder-coated aluminum
Electrical
Circuit breaker 20 amps/12 V DC; 15 amps/24 V DC
Wiring 12 ga. (up to 20 ft./6.1 m from breaker)
Water
Supply
Fitting 0.5 in. (13 mm) ID exible water line
Flow rate 2.0 gpm/7.6 lpm minimum
Discharge
Inside diameter 1.5 in./38 mm or 1 in./25 mm
Horizontal run 98 ft./30 m maximum
Vertical run 9.8 ft./3 m maximum
Specications are subject to change without notice.
