Dometic RM 5310 User Manual

4.12 Changing the decor panel
 Remove the door, see “ 4.11 Changing the
doorhang
”.
 Loosen three screws of the lower moulding
and remove trim moulding.
 Withdraw the decor panel by sliding it
downwards . Fit new panel and slide it
upwards as far as possible.
 Fit the trim moulding back in place.
 Fit the door on the hinge pin.
Model RM 5310
Decor panel dimensions :
Height Width Thickness
532 +/-1 mm 453 +/-1 mm max. 3,8 mm
Model RM 5330
Height Width Thickness
740 mm 453,5 mm max. 3,8 mm
Model RM 5380
Height Width Thickness
740 mm 453,5 mm max. 3,8 mm
18
Refrigerator operation
Fig. 41
Fig. 42
Fig. 39
1
3
Fig 40
2
4
Fig. 43
Fig. 44
4.13 Winter operation
In Winter, check regularly that the ventilation
grilles and the exhaust duct system (1) have
not been blocked by snow, leaves, etc.
When the outside temperature falls below
+10°C, the winter cover (2) should be fitted.
This protects the unit from excessively cold air
which could have adverse effects on the per-
formance of the unit.
You should also attach the winter cover if the
vehicle is taken out of service for a longer
period of time or while it is being cleaned from
the outside.
1
2

Dometic RM 5310 Specifications

General

Climate class	SN
Total net capacity	55 L
Total gross capacity	60 L
Minimum operating temperature	10 °C
Lamp type	LED
Fridge net capacity	50 L
Fridge interior light	Yes
Number of vegetable drawers	-
Freezer position	Top-placed
Freezing capacity	- kg/24h
Freezer net capacity	5 L
Storage time during power failure	- h
Current	0.54 A
Power source	Gas/Electric
Connected load	125 W
Gas consumption	270 g/24h
AC input voltage	230 - 240 V
AC input frequency	50 - 60 Hz
Door hinge	Left
Control type	Rotary
Product color	Black, Grey
Appliance placement	Freestanding
Refrigerating medium	R717
Package depth	543 mm
Package width	523 mm
Package height	635 mm
Package weight	24000 g

Weight and Dimensions

Depth	474 mm
Width	486 mm
Height	618 mm
Weight	20000 g
