Repair & Maintenance
31
The service mode starts with showing all “LEDs
on” for 3 seconds, followed by stating the SW
version status and then service mode sequence
starts as on normal 8 series fridges.
5.2 Displaying Software versions
of power module (RMD 8xxx)
Fig. 44
Fig. 45
Step 6:
activates frame heating
Step 7:
activates interior lights (Except for electrical
lock)
Step 8:
Intern test step (is not indicated)
Step 9:
Recognizing electrical lock or reed switch
Step 10:
activates all 7 segment-components one after
the other
Step 11:
activates all LED´s
To leave the diagnosis mode: Push button „2“
repeatedly or wait for 10 minutes.
Caution: Changes then are not saved or if
„Mode“ button is used!
MES :
stating the SW version status via operating LED
and temperature LEDs.
Example : Software version V 1.2
AES :
stating the SW version status via display
Example : Software version V 1.66
Probably starting with season 2010 these
functions will be valid for all models RM
8xx1 and models RM 8xx5.
