SinePower Fastening the inverter
11
The inverter has the following connections, displays and control elements:
I
6 Fastening the inverter
You can fasten the inverter using the four holders supplied.
When selecting the installation location, observe the following instructions:
• The inverter can be mounted horizontally or vertically.
• The inverter must be installed in a place that is protected from moisture.
• The inverter may not be installed in the presence of flammable materials.
• The inverter may not be installed in a dusty environment.
• The place of installation must be well-ventilated. A ventilation system must be
present for installations in small, closed spaces. The minimum clearance around
the inverter must be at least 25 cm.
NOTE
The version for continental Europe is depicted.
Pos. in
fig. 1, page 3
Element
1 Switches
0: device is switched off
I: device is switched on
2 Green Status LED: lights up when inverter is in operation
3 Red Status LED: indicates malfunction
4 USB port
5 MSI412, MSI424 only: Connection for external switch
6 Cover for 230 Vwsafety socket
7 Holders
Pos. in
fig. 2, page 4
Element
1 Connection cable for direct current
2Fan
MSI200-MSI400-IO-16s.book Seite 11 Freitag, 27. Oktober 2017 9:59 21
