8 9
EN EN
Installation Charging
Note:
•
The vacuum cannot be used while charging.
•
Fully charging the vacuum takes about 3.5 hours. Vacuuming in Turbo Mode for
a prolonged time will cause the battery to heat up, which increases the charging
time. Allow the vacuum to cool down for 30 minutes before charging it.
•
Check the current battery level on the LED battery status indicator or display
screen.
LED Battery Status Indicator
Display Screen
2-in-1 Charging & Storage Mount Installation Diagram
1. Paste the mounting template sticker on the wall and keep it parallel to the ground.
It is recommended that the bottom of the sticker is at least 119 cm o the ground.
2. Use a power drill with an 8 mm drill bit to drill a hole into each hole marker on the
mounting template sticker, then insert a wall plug into each hole.
3. Align the locating holes on the mount with the holes on the mounting template
sticker. Then, fasten the mount to the wall with the included screws.
The 2-in-1 charging & storage mount is an optional accessory. You can install it
based on your needs.
Fully charge the vacuum before using it for the rst time.
Note: The mount should be installed in a cool, dry place with power outlets nearby.
Before installation, make sure that there are no electrical wires or pipes directly
behind where the mount will be installed.
Note: Once the vacuum is fully charged, the indicator will turn o after 5 minutes,
and the device will enter energy-saving mode.
Low battery
Half battery
Nearly full
Fully charged
The number on the display screen represents the current battery level in a percentage
during charging. When the number becomes 100, the battery is fully charged.
O Blinking
On
119cm
