DSC LCD4500 User Manual

11
If a multi partition access code is entered the keypad will display the
message
(0) TO ARM(0) TO ARM
(0) TO ARM(0) TO ARM
(0) TO ARM
< >< >
< >< >
< >
(Partition Label)(Partition Label)
(Partition Label)(Partition Label)
(Partition Label)
RR
RR
R
..
..
.
The lower right hand corner of the display will show the partition status using
the letter “R” for Ready, “N” for Not ready, “A” for Armed and “!” for partition
is in alarm.
Use the [<] [>] keys to scroll though the assigned partitions. Only partitions
to which the access code is assigned will be displayed. The message
(2) TO SELECT(2) TO SELECT
(2) TO SELECT(2) TO SELECT
(2) TO SELECT
< >< >
< >< >
< >
(Partition Label)(Partition Label)
(Partition Label)(Partition Label)
(Partition Label)
RR
RR
R
with the partition status at the lower right hand side of the LCD.
To arm the partition which you are in simply press [✱] or use the hotkey (0).
The message
EXIT DELAYEXIT DELAY
EXIT DELAYEXIT DELAY
EXIT DELAY
IN PROGRESSIN PROGRESS
IN PROGRESSIN PROGRESS
IN PROGRESS
will appear on the keypad with the exit delay timer if it is enabled. Instead of
arming their own partition, if the user decides to select another partition to
arm the message
SELECT (0)SELECT (0)
SELECT (0)SELECT (0)
SELECT (0)
< >< >
< >< >
< >
ARM PARTITIONARM PARTITION
ARM PARTITIONARM PARTITION
ARM PARTITION
RR
RR
R
will be displayed. Use the arrow keys to scroll to the “For Options” menu.
Selecting (0) “To Arm” will arm the selected partition and display the message
EXIT DELAYEXIT DELAY
EXIT DELAYEXIT DELAY
EXIT DELAY
IN PROGRESSIN PROGRESS
IN PROGRESSIN PROGRESS
IN PROGRESS
for 2 seconds and then return the user to the arming menu of their own
partition.
If (1) “For Options” is selected the user will be prompted with the message
ACCESSINGACCESSING
ACCESSINGACCESSING
ACCESSING
(Partition Label)(Partition Label)
(Partition Label)(Partition Label)
(Partition Label)
..
..
.
From here the user is capable of performing all [✱] functions (e.g. [✱] [7]
Door Strike) and arm the panel using conventional methods.
Once the [#] key is pressed or the programmable amount of idle time (no
key presses made or not active in a submenu) the keypad will return to its
home partition displaying the message
RETURNING TORETURNING TO
RETURNING TORETURNING TO
RETURNING TO
(Partition Label)(Partition Label)
(Partition Label)(Partition Label)
(Partition Label)
..
..
.
