Installation and Operation of 613 & E Series Gas Fired Convection Oven
4
HEATING VALUE 1000 BTU 37.3 MJ/m
3
2550 BTU 90.0 MJ/m
3
SPECIFIC GRAVITY 0.63 0.63 1.53 1.53
GAS PRESSURE AT MANIFOLD 3.5" W.C. 0.87 kPa 10" W.C. 2.49 kPa
PER BURNER 20,000 BTU/HR 5.9 kW 20.000 BTU/HR 5.9 kW
PER OVEN 40,000 BTU/HR 11.8 kW 40,000 BTU/HR 11.8 kW
PER BURNER 23,000 BTU/HR 6.8 kW 23.000 BTU/HR 6.8 kW
PER OVEN 46,000 BTU/HR 13.5 kW 46,000 BTU/HR 13.5 kW
STANDARD DEPTH #44 2.18mm #55 1.32mm
DEEP DEPTH #43 2.26mm #54 1.40mm
