Installation and Operation of 613 & E Series Gas Fired Convection Oven
Screws (4)
Flue Trim
Flue Extension
(153074)
10Ð24 X 1/2"
Hex Washer Head
Screws (6)
Screws (3)
Stacking Bracket
(153233)
1. Remove existing ue trim from the top of oven.
2. Insert ue extension thru top opening rst
and then
align holes on ue extension with holes on rear
panel of oven.
3. Use 6 of the 8 screws (10-24x1/2") hex washer
head that are provided to attach the ue extension
to the rear panel of the oven as shown in gure.
The other 2 screws are extras and are not used.
4. Re-install the existing ue trim.
1. On rear of top oven remove two existing screws
that attach the side panel to the base.
2. On rear of bottom oven remove one existing
screw that attaches the top to the side panel.
3. Install stacking bracket using the existing
screws as shown in gure.
4. Repeat steps to install second stacking bracket
on other side.
