Eaton 9130 UPS User Manual

INTRODUCTION
Eaton
®
9130 UPS (700–3000 VA) User's Guide S 164201718 Rev 3 www.eaton.com/powerquality
2
Figure 1 shows the Eaton 9130 rackmount UPS, and Figure 2 shows the
optional rackmount EBM.
Figure 1. The Eaton 9130 Rackmount UPS
Figure 2. The Eaton 9130 Rackmount EBM
Figure 3 shows the Eaton 9130 tower UPS and optional EBM.
Figure 3. The Eaton 9130 Tower UPS and EBM (2000–3000 VA Models Shown)

Eaton 9130 UPS Specifications

General

Transfer Time	0 ms
Waveform Type	Sine wave
Output Voltage	200/208/220/230/240V
Input Voltage Range	160-294V (adjustable to 140-300V)
Frequency Range	50/60 Hz ± 3 Hz (auto sensing)
Efficiency	Up to 95%
Form Factor	Rack/Tower Convertible
Battery Type	Sealed, lead-acid
Communication Interface	USB, RS-232, Relay
Typical Recharge Time	3 hours
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-15°C to 45°C (5°F to 113°F)
Relative Humidity	0% to 95% (non-condensing)
Safety Approvals	UL, cUL, CE
