Eaton 9130 UPS User Manual

UPS MAINTENANCE
Eaton
®
9130 UPS (700–3000 VA) User's Guide S 164201718 Rev 3 www.eaton.com/powerquality
69
Replacing Rackmount EBMs
C A U T I O N
The EBM is heavy (see page 78). Lifting the cabinet into the rack requires a minimum of two
people.
To replace the EBMs:
1. Remove the front cover of each EBM. See Figure 27.
To remove the cover, remove and retain the two screws on the
right side of the cover. Grasp the sides of the cover and slide the
cover to the left and then away from the cabinet.
Bottom EBM Cable Knockout
(underneath cover)
Top EBM Cable Knockout
EBM Cover Hook
Figure 27. Removing the EBM Front Cover
