Eaton 9155 UPS (8–15 kVA) User's Guide S 164201553 Rev G (www.eaton.com/powerquality)
7
Chapter 3 UPS Setup
This chapter describes:
S Equipment inspection
S Floor loading and clearances
S Unloading the cabinet(s)
S Selecting an installation option
The instructions are intended for the chief operator/system supervisor, electrical
consultants, and installation electricians. Local regulations and electrical code must be
followed during the UPS installation.
Inspecting the Equipment
If any equipment has been damaged during shipment, keep the shipping and packing
materials for the carrier or place of purchase and file a claim for shipping damage. If
you discover damage after acceptance, file a claim for concealed damage.
To file a claim for shipping damage or concealed damage: 1) File with the carrier
within 15 days of receipt of the equipment; 2) Send a copy of the damage claim
within 15 days to your service representative.
NOTE Check the battery recharge date on the packaging label. If the date has expired and the batteries
were never recharged, do not use the UPS. Contact your service representative.
Floor Loading
When planning the installation, consider the UPS weight for floor loading. The
strength of the installation surface must be adequate for point and distributed
loadings. The approximate weights are shown in the following table.
Standard Model Floor Loadings (2-High/3-High Cabinets)
Eaton 9155 Maximum Weight (lb) Point Loading (lb/in
2
) Distributed Loading (lb/ft
2
)
2-High UPS 352 88 166
3-High UPS 590 148 278
2-High UPS with Maintenance Bypass Module
(MBM) or Power Distribution Module (PDM)
3-High UPS with MBM/PDM
3-High UPS with Isolation Transformer 558 140 263
2-High EBM 480 120 226
3-High EBM 710 178 335
