Eaton 9355 UPS (10/15 kVA) User’s Guide 164201594—Rev H0 103
CChhaapptteerr 1100 PPrroodduucctt SSppeecciiffiiccaattiioonnss
This section provides the following specifications:
• Model list
• Dimensions and weights
• Environmental and safety specifications
• Technical specifications
• Model specifications
• Battery specifications
• Battery runtimes
Table 14. Model List
UPS
Description
Power Rating
9355-10-32
2-high: UPS with one battery section
3-high: UPS with one battery and one isolation
transformer section
10 kVA, 9 kW
9355-10-64
3-high: UPS with two battery sections
10 kVA, 9 kW
9355-15-32
2-high: UPS with one battery section
3-high: UPS with one battery and one isolation
transformer section
15 kVA, 13.5 kW
9355-15-64
3-high: UPS with two battery sections
15 kVA, 13.5 kW
Extended Battery
Module (EBM)
Description
EBM-64 2-high: two battery sections
EBM-96 3-high: three battery sections
Table 15. Dimensions and Weights
Dimensions (H x W x D)
Weight
2-High UPS 32.2" x 12" x 33.5" (81 x 30 x 85 cm) 381 lb (173 kg)
3-High UPS-32 47.8" x 12" x 33.5" (121.5 x 30 x 85 cm) 587 lb (266 kg)
3-High UPS-64 47.8" x 12" x 33.5" (121.5 x 30 x 85 cm) 619 lb (281 kg)
2-High EBM
32.2" x 12" x 30.3" (81 x 30 x 77 cm) 480 lb (218 kg)
3-High EBM
47.8" x 12" x 30.3" (121.5 x 30 x 77 cm) 710 lb (322 kg)

Eaton 9355 Specifications

General

Efficiency	91 %
Noise level	58 dB
Output power	27000 W
Input frequency	50/60 Hz
Audible alarm(s)	Yes
Input power factor	0.99
Output power factor	0.9
Output power capacity	30 kVA
Input operation voltage (min)	220 V
Input current Total Harmonic Distortion (THD)	5 %
RS-232 ports	1
AC outlet types	-
AC outlets quantity	- AC outlet(s)
Safety	IEC 62040-1-1, IEC 60950, EN 62040-1-1, UL 1778, NOM-0190SCP8-1993
Form factor	Tower
Display type	LCD
Certification	EN 50091-2 Class A\\r UL, cUL, NOM-NYCE
Product color	Black
Battery technology	Sealed Lead Acid (VRLA)
Typical backup time at half load	- min
Operating altitude	0 - 3000 m
Storage temperature (T-T)	0 - 25 °C
Operating temperature (T-T)	10 - 40 °C

Weight and Dimensions

Depth	866.14 mm
Width	508 mm
Height	1676.4 mm
