Table 16. Command menu operation
Function
Subfunction
Operation
UPS Control
Commands
Use the or push button to
highlight the desired command function,
then press the push button to
execute the command or proceed to
further command screens.
Normal Mode
Starts the UPS in the standard normal
mode or transfers the UPS from the
bypass mode to the standard normal
mode.
Bypass Mode
Starts the UPS in the bypass mode or
transfers the UPS from the normal
mode to the bypass mode.
High-Efficiency
(HE) Mode
Transfers the UPS from the standard
normal mode to the HE mode.
Transfers the UPS from the HE mode to
the standard normal mode.
Battery Control
Commands
Use the or push button to
highlight the desired command function,
then press the push button to
execute the command.
Charger
Turns the battery charger on.
Resting
Turns the battery charger off.
Table 17. Typical system status messages
Function
Message
UPS
Load Off; Bypass; Online, HE
Bypass
Off; On; Available
Charger
Charger Resting; Charger

Eaton 93E Specifications

General

Topology	Double Conversion Online
Frequency	50/60 Hz
Output Voltage	220/230/240V
Battery Type	VRLA
Form Factor	Tower
Typical Backup Time	Depends on configuration
Communication Ports	RS232, USB, Relay, Optional SNMP/Web Card
Operating Temperature	0°C to 40°C
Humidity	0-95% non-condensing
Dimensions	Varies with model
Weight	Varies with model
Certifications	UL, CE, cUL
