If error conditions are detected, the LCD may display the
following messages:
If the "Configuration Value Required!" message appears, refer
to Section 3: Initial Programming. Perform basic program-
ming steps and then initiate a self-test.
Indication messages
The fourth line of the LCD is used to provide messages
associated with menu mode indications. These indication
messages can be defined with up to 20 characters.
Displayed during Power-Up/Reset Mode:
•
(PASS)
•
(ATTENTION)
•
(ATTENTION...MORE )
•
(ATTENTION...LAST )
•
(FAILURE)
•
(FAILURE...MORE )
•
(FAILURE...LAST )
Displayed when an invalid function code is entered:
•
(INVALID FUNCTION)
Displayed when an invalid security code is entered:
•
(INVALID SECURITY)
Displayed when a parameter cannot be read, written,
or reset because the proper security code has not been
entered:
•
(IMPROPER SECURITY)
Displayed when edit/reset mode is active:
•
(EDIT)
•
(CONFIRM) (also displayed to prompt the user when
issuing a command from the menu system, i.e., PMT
Mode A Issue Test)
Displayed when a value that has been entered is out of the
valid range:
•
(VALUE TOO HIGH)
•
(VALUE TOO LOW)
•
(OUT OF RANGE)
•
(INVALID DATE)
•
(INVALID TIME)
Displayed when listing alarms or events:
•
(MORE... )
•
(LAST... )
Displayed when the user access Master Reset:
•
(PRESS RESET)
•
(DONE)
Displayed when an alarm is to be acknowledged or unac-
knowledged by the user:
•
(ACKNOWLEDGE)
•
(UNACKNOWLEDGED)
Self-Test Complete.
Clock Needs Setting!
(ATTENTION...MORE )
Self-Test Complete.
Input Voltage
Missing!
(ATTENTION...MORE )
Self-Test Complete.
Output Voltage
Missing!
(FAILURE...MORE )
Self-Test Complete.
No Neutral
Sync Signal!
(ATTENTION...LAST )
Self-Test Complete.
Configuration Value
Required!
(ATTENTION...MORE )
Self-Test Complete.
Factory Calibration
Required!
(ATTENTION...MORE )
Self-Test Complete.
Data Acquisition!
(FAILURE...MORE )
74
CL-6 SERIES CONTROL INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225016EN January 2016
