Eaton Cutler-Hammer User Manual

IB01602002E
Page 3
Effective 10/02
Rating When Used with Upstream Circuit Breker Rating When Used with Upstream Fuse
Transfer Switch Option 17C 240V 480V 600V Maximum Fuse 600V max.
Amp Rating Selected (kA) (kA) (kA) Fuse Rating Type (kA)
600 No 85 65 25 800/1200 L 200
800 No 85 65 25 1200/1600 L 200
1000 No 85 65 25 1600 L 200
1200 No 85 65 25 2000 L 200
800 Yes 100 100 85 1200/1600 L 200
1000 Yes 100 100 85 1600 L 200
1200 Yes 100 100 85 2000 L 200
1600 100 100 85 3000 L 200
2000 100 100 85 3000 L 200
2500 100 100 85 4000 L 200
3000 100 100 85 4000 L 200
4000 100 100 85 5000 L 200
Table 1.1 Withstand Ratings
