Eaton DSII Series User Manual

a. Shunt Trip b. Trip Shaft Adjustment
Trip Latch Trip Shaft Lever
Trip Latch Pivot Pin Trip Shaft
Roller Constraining Link Trip Shaft Latch Surface
Shunt Trip Device Main Drive Link
Shunt Trip Armature Trip Shaft Adjusting Screw
Shunt Trip Coil Trip Actuator
Figure 5-5 Shunt Trip Details Showing Trip Shaft Adjustment
Anti-Rebound Latch
Open Position Stop (adjustable for DSII-632 only)
Figure 5-6 Open Position Stop and Anti-Rebound Latch
Effective July 2010
Instructional Book IB694C694-03
57
EATON CORPORATION www.eaton.com
