8 Dimensions
8.2 Adapters
52 EMS2… Electronic motor starter 10/19 MN034003EN www.eaton.com
8.1.3 Plug-in motor starters
• EMS2-ROSF-…
Figure 27: EMS2-ROSF-…
8.2 Adapters
167.4 mm (6.59")
22.5 mm
(0.89")
114 mm (4.49")
125 mm (4.92")
Figure 28: EMS2-XTH Figure 29: EMS2-XBB60
22.5 mm
(0.89")
34 mm
(1.34")
185 mm (7.28")
22.5 mm
(0.89")
41.5 mm
(1.63")
60 mm
(2.36")
60 mm
(2.36")
200 mm (7.87")
