TM293 MEDC DB3BM UL Technical Manual
SOUNDER/HORN – DB3BM UL TM293.A August 2022 www.eaton.com
TONE No. TONE FREQUENCY/DESCRIPTION SWITCH SETTING 12345 Voltage free stage selection tone No.
DC AC
Stage 1 Stage 2 Stage 3 Stage 4 Stage 5 Stage2
1 Alt Tones 800/970Hz at 1/4 sec 11111 T14 T10 T11 T8 T14
2 Sweeping 800/970Hz at 7 Hz 11110 T14 T10 T1 T8 T14
3 Sweeping 800/970Hz at 1 Hz 11101 T14 T10 T1 T8 T14
4 Continuous at 2850Hz 11100 T14 T10 T1 T8 T14
5 Sweeping 2400-2850Hz at 7Hz 11011 T14 T10 T1 T8 T14
6 Sweeping 2400-2850Hz at 1Hz 11010 T14 T10 T1 T8 T14
7 Slow Whoop 11001 T14 T10 T1 T8 T14
8 Sweep 1200-500Hz at 1Hz 11000 T14 T10 T1 T6 T14
9 Alt Tones 2400/2850Hz at 2Hz 10111 T14 T10 T1 T8 T14
10 Int Tone of 970Hz at 1Hz 10110 T14 T12 T1 T8 T14
11 Alt Tones 800/970Hz at 7/8Hz 10101 T14 T10 T1 T8 T14
12 Int Tone at 2850Hz at 1Hz 10100 T14 T10 T1 T8 T14
13 970Hz at 1/4 sec on 1 sec off 10011 T14 T10 T1 T8 T14
14 Continuous at 970Hz 10010 T28 T10 T1 T8 T28
15 554Hz for 0.1S/440Hz for 0.4S 10001 T14 T10 T1 T8 T14
16 Int 660Hz 150 mS on 150 mS off 10000 T14 T10 T1 T8 T14
17 Int 660Hz 1.8 sec on 1.8 sec off 01111 T14 T10 T1 T8 T14
18 Int 660Hz 6.5 sec on 13 sec off 01110 T14 T10 T1 T8 T14
19 Continuous 660Hz 01101 T14 T10 T1 T8 T14
20 Alt 554/440Hz at 1Hz 01100 T14 T10 T1 T8 T14
21 Int 660Hz at 7/8Hz 01011 T14 T10 T1 T8 T14
22 Int 2850Hz 150 mS on 100 mS off 01010 T14 T10 T1 T8 T14
23 Sweep 800-970Hz at 50Hz 01001 T14 T10 T1 T8 T14
24 Sweep 2400-2850Hz at 50Hz 01000 T14 T10 T1 T8 T14
25 3x970Hz pulses 0.5 off, 1.5 off 00111 T14 T10 T1 T8 T14
26 3x2850Hz pulses 0.5on/0.5off, 1.5 off 00110 T14 T10 T1 T8 T14
27 Int 3100Hz 0.32s on/0.68s off 00101 T14 T10 T1 T8 T14
28 Continuous 1400Hz 00100 T14 T10 T1 T8 T14
29 Spare / Custom tone 00011
30 Spare / Custom tone 00010
31 Spare / Custom tone 00001
32 Spare / Custom tone 00000
Tone table 2: Pre-selected tone details for voltage-free activation stages:
TONE No. TONE FREQUENCY/DESCRIPTION SWITCH SETTING 12345 TONE DESCRIPTION Nominal SPL (dB(A) @ 1M)
22 Int 2850 Hz 150 mS on 100 mS off 01010 Pelican Crossing 111
23 Sweep 800-970 Hz at 50 Hz 01001 Low Freq. Buzz 109
24 Sweep 2400 -2850 Hz at 50 Hz 01000 High Freq. Buzz 111
25 3x970 Hz pulses 0.5 off, 1.5 off 00111 112
26 3x2850 Hz pulses 0.5on/0.5off, 1.5 off 00110 112
27 Int 3100 Hz 0.32s on/0.68s off 00101 105
28 Continuous 1400 Hz 00100 125
29 Spare / Custom tone 00011
30 Spare / Custom tone 00010
31 Spare / Custom tone 00001
32 Spare / Custom tone 00000
ote: N If special tones were requested at the time of ordering, please see the separate
tones list supplied with the unit for details of these special tones and their
respective switch settings.
