2. Installation
1
2
4
Input/output junction box bracket system (included with power module rail kit, part
number 68001)
This bracket will maintain the Input/Output box at the rear of the rack enclosure when hot-swapping the
power module.
It will then be easier to slide the replacement module into the connectors of the Input/Output box.
3
4
Rear bracket system (included with rail kits, part numbers 68001 and 68002)
1
1
To be used if you need to move the
rack enclosure with UPS already
rack-mounted inside.
3
2
2
3
