Communication Options
The Eaton 9355 UPS UPS has serial communication capabilities through
the DB-9 communication port or through an X-Slot card in one of the
available bays. In addition, the LanSafe Power Management Software
can be installed and used to communicate with the UPS via one of the
serial communication connections.
The UPS supports two serial communication devices according to the
following table:
Independent Multiplexed
X-Slot 1 X-Slot 2 DB-9 Communication Port
Any X-Slot card Any X-Slot card except the Eaton
Modem Card
Not in use
Any X-Slot card Eaton Relay Interface Card
Powerware Hot Sync CAN Bridge Card
Available
Any X-Slot card Not in use Available
NOTE You can configure relays, signal inputs, and the serial port baud rate through the
front panel menus (see Table 9 on page 84).
DB-9 Communication Port
To establish communication between the UPS and a computer, connect
your computer to the UPS communication port using the supplied
communication cable.
When the communication cable is installed, power management
software can exchange data with the UPS. The software polls the UPS
for detailed information on the status of the power environment. If a
power emergency occurs, the software initiates the saving of all data
and an orderly shutdown of the equipment.
